Fast Recovery Diodes
(Hockey PUK Version), 560 A
SD553C..S50L Series
Vishay High Power Products
FEATURES
• High power FAST recovery diode series
• 6.0 µs recovery time
• High voltage ratings up to 4500 V
• High current capability
• Optimized turn-on and turn-off characteristics
• Low forward recovery
• Fast and soft reverse recovery
• Press PUK encapsulation
• Case style conform to JEDEC DO-200AB (B-PUK)
• Maximum junction temperature 125 °C
• Lead (Pb)-free
TYPICAL APPLICATIONS
• Snubber diode for GTO
• High voltage freewheeling diode
• Fast recovery rectifier applications
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
F(AV)
560 A
DO-200AB (B-PUK)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
F(AV)
560 A
T
hs
55 °C
I
F(RMS)
1120 A
T
hs
25 °C
I
FSM
50 Hz 12 000
A
60 Hz 12 570
I 2 t
50 Hz 721
kA 2 s
60 Hz 658
V
RRM
Range 3000 to 4500 V
t
rr
6.0 µs
T
J
125
°C
T
J
- 40 to 125
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
RRM
, MAXIMUM REPETITIVE
PEAK REVERSE VOLTAGE
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK REVERSE VOLTAGE
V
I
RRM
MAXIMUM
AT T
J
= 125 °C
mA
SD553C..S50L
30 3000 3100
75
36 3600 3700
40 4000 4100
45 4500 4600
