- 6 -
AL600ULX Series
Appendix A - UL Listed Compatible Devices
A.1 Four (4) Wire Smoke Detectors
Table A-1 below lists four (4) wire smoke detectors compatible with AL600ULX output.
System Sensor
Smoke Detector/Base
Detector Type
Max Stand-by
Current (mA)
Alarm
Current (mA)
B112LP
Base
0.12
36
B114LP
Base
*
*
B404B
Base
*
*
DH100ACDC
Photoelectric
0.15
0.70
DH100ACDCLP
Photoelectric
0.15
0.70
DH100ACDCLPW
Photoelectric
0.15
0.70
DH400ACDCI
Ionization Duct
25
95
DH400ACDCP
Photoelectric Duct
25
95
1112/24/D
Ionization
0.05
50
1424
Ionization
0.10
41
1451 (w/B402B Base)
Ionization
0.10
39
2112/24ATR
Photoelectric
0.50
60/70
2112/24AITR
Photoelectric
0.50
60/70
2112/24/D
Photoelectric
0.05
50
2112/24T/D
Photoelectric w/135
o
Thermal
0.05
50
2112/24TSRB
Photoelectric w/135
o
Thermal Supervisory Relay
15
45
2312/24TB
Photoelectric
0.12
50
2412 (12 volt)
Photoelectric
0.12
77
2424
Photoelectric
0.10
41
2451
Photoelectric
0.10
39
2451TH (with/B402B Base)
Photoelectric
0.10
39
2W-MOD
Loop Test/Maintenance Mod.
30
50
4W-B (12/24 volt)
Photoelectric I
3
.05
23
4WT-B (12/24 volt)
Photoelectric I
3
w/Therm
.05
23
4WTA-B (12/24 volt)
I
3
Photo w/Therm/Sounder
.05
35
4WTR-B (12/24 volt)
I
3
Photo w/Therm/Relay
.05
35
4WITAR-B (12/24 volt)
I
3
Photo w/Isolated Therm/Sounder/Relay
.05
50
2W-MOD2
I
3
Loop Test/Maintenance Mod.
.05
*
RRS-MOD
I
3
Reversing Relay/Sync Module
.05
*
6424
Projected Beam
10
28.4
Beam 1224(S)
Projected Beam
17
38.5
* Contact manufacturer for current draws.
A.2 Relays
Table A-2 below lists relays compatible with AL600ULX output.
Manufacturer
Model
Current (mA)
Manufacturer
Model
Current (mA)
System Sensor
PR-1
PR-2
PR-3
EOLR-1
R-10T
R-14T
15
30
30
30
23
23
System Sensor
R-20T
R-24T
R-10E
R-14E
R-20E
R-24E
40
40
23
23
40
40
