- 2 - AL600ULX Series
Overview:
The AL600ULX is a power supply that converts a 115VAC / 60Hz input, to a 12VDC or 24VDC regulating output
(see specifications below). The AL600ULX is the base power supply unit for the UL Listed multi-output power
supply/charger series: AL600ULPD4, AL600ULPD4CB, AL600ULPD8, AL600ULPD8CB, AL600ULXPD16,
AL600ULXPD16CB (Refer to AL600ULX Series Power Supply Configuration Reference Chart below).
AL600ULX Series Power Supply Configuration Reference Chart:
Altronix
Model Number Accessory Power Distribution Module(s) Number of Output(s) Class 2 Rated Power Limited Outputs Fused Outputs PTC Outputs Output Rating (amp) per Output Agency Listings UL Listings and File Numbers
AL600ULX
AL600ULXR
AL600ULXX
------ 1 ------ ------ ------ 6
UL File # S4707
UL 1481
UL Listed Power
Supplies for
Fire Protective
Signaling
Systems.
----------------------------------------
UL 294
UL Listed for
Access Control
System Units.
AL600ULPD4 PD4UL 4 ------ x ------ 3.5
AL600ULPD4CB PD4ULCB 4 x -------- x 2.5
AL600ULPD8 PD8UL 8 ------ x ------ 3.5
AL600ULPD8CB PD8ULCB 8 x ------ x 2.5
AL600ULXPD16 Two (2) PD8UL 16 ------ x ------ 3.5
AL600ULXPD16CB Two (2) PD8ULCB 16 x ------ x 2.5
Do not exceed total output rating of 6 amp per unit.
AL600ULPD4/CB and AL600ULPD8/CB available in larger enclosure add X to model (eg. AL600ULXPD4/CB).
Specifications:
Output
Voltage
Type
Voltage
Output Current
Frequency Ripple
Voltage
Normal
Stand-by
Stand-by Battery
Minimum Operating Time
Maximum
(alarm)
Stand-by Battery
Minimum Operating Time
DC Output
12VDC & 24VDC
DC See Stand-by Specifications pg. 3 N/A 300mV
Power Supply Output Specifications:
Output Switch Position
12VDC SW1 - CLOSED (Fig. 1b, pg. 3)
24VDC SW1 - OPEN (Fig. 1b, pg. 3)
Agency Listings:
• UL Listed for Access Control System Units
(UL 294) and UL Listed Standard for Safety for
Fire Protective Signaling Systems (UL 1481).
• NFPA 72 compliant (Fire-Protective Signaling Service).
Input:
• Input 115VAC / 60Hz, 3.5 amp.
Output:
• 12VDC or 24VDC selectable output(s).
• 6 amp continuous supply current at 12VDC or 24VDC.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
Battery Backup (cont’d):
• Automatic switch over to stand-by battery when
AC fails.
• Maximum charge current 0.7 amp.
• Zero voltage drop when switched over to
battery backup.
Supervision:
• AC fail supervision (form “C” contacts).
• Low battery supervision (form “C” contacts).
• Battery presence supervision (form “C” contacts).
Additional Features:
• AC input, DC output and BAT trouble LED indicators.
• Power supply, enclosure, cam lock and battery leads.
• All models are available in red enclosure
(add an “R” suffix to the part # e.g. AL600ULPD8R).
Altronix Corp. 140 58th St. Brooklyn, NY
California State
Fire Marshal
NYC Dept.
of Buildings
Factory
Mutual
Approved
