- 2 -

AL642ULADA

Agency Listings:

• UL Listed Control Units and Accessories for

Fire Systems (UL 864).

• MEA - NYC Department of Buildings Approved.

• CSFM - California State Fire Marshal Approved.

• FM - Factory Mutual Approved.

• NFPA 72 Compliant.

Input:

• Power input 120VAC 60 Hz, 4 amp.

• Two (2) Class A, Style Z or two (2) Class B,

Style W, X, Y FACP inputs.

• Two (2) NC dry contact trigger inputs.

Output:

• Class 2 Rated power limited outputs.

• 24VDC voltage regulated power limited outputs.

• 6.5 amp max total alarm current.

• 2.5A max current per output.

• Two auxiliary outputs rated at 1 amp each

(1 amp continuous, 1 amp AC disconnect).

• Two (2) outputs may be paralleled for more power on

an indicating circuit (see 42 Application Guide).

• Programmable supervised indicating circuit outputs:

Four (4) Class B, Style W, X, Y or Four (4) Class A,

Style Z or Two (2) Class A, Style Z and Two (2) Class B,

Style W, X, Y (see 42 Application Guide).

• Thermal and short circuit protection with auto reset.

Battery Backup:

• Charging voltage is 26.2-26.4VDC.

• Built-in charger for sealed lead acid or gel type batteries.

• Automatic switchover to stand-by battery when

AC fails.

• Zero voltage drop when switching over to

battery backup.

Supervision:

• AC fail supervision (form “C” contact, 1 amp / 28VDC).

Factory set for 30 seconds with optional 2.5 to 3 hour

delay setting (field selectable).

Supervision (cont.):

• Instant local AC trouble reporting relay

(form “C” contact, 1 amp / 28VDC).

• Battery presence and low battery supervision

(form “C” contact, 1 amp / 28VDC).

Visual Indicators:

• Input and output status LED indicators.

Special Features:

• 2-wire horn/strobe Sync mode allows audible

notification appliances (horns) to be silenced

while visual notification appliances (strobes)

continue to operate.

• Sync protocols include Potter/Amseco, Faraday,

Gentex

®

,

System Sensor

®

, and CooperWheelock

®

.

• Temporal Code 3, Steady Mode, Input to Output

Follower Mode (maintains synchronization of

notification appliances circuit).

• Compatible with 24VDC fire panels.

• Output loop supervision directed to input 1 or input 2.

• Signal Circuit Trouble Memory - facilitates quick

identification of an intermittent/fault (short circuit, open

or ground) which has previously occurred on one or

more signaling circuit outputs. LEDs indicate/identify

which output the fault has occurred.

• Common trouble input and output for external trouble

signals tie-in.

• Ground fault detection.

• Unit includes power supply, logic board enclosure,

cam lock, and battery leads.
Enclosure Dimensions (approx. H x W x D):
18” x 14.5” x 4.5” (457.2mm x 368.3mm x 114.3mm).

Overview:

The Altronix AL642ULADA is an extremely cost effective 6.5 amp remote power supply/battery charger. It may be con-

nected to any 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC

such as strobes and horns) expansion support to meet ADA requirements. It also provides auxiliary power to support system

accessories. The unit delivers electronically regulated and filtered 24 volt power to Class B, Style W, X, Y or Class A, Style

Z NAC loop circuits. Additionally, a separate 1 amp auxiliary output for 4-wire smoke detectors is available. The 6.5 amp

max. alarm current can be divided between the four (4) outputs for powering NAC devices. Each output is rated at 2.5 amp

max., and can be independently programmed for Steady, Temporal Code 3 or Strobe Synchronization. All outputs may be

programmed for Input to Output Follower Mode (output will follow input. i.e. March Time Input, March Time Output). An

individual output of 4 amp is achieved by paralleling 2 outputs. In non-alarm condition independent loop supervision for

Class A, Style Z and/or Class B, Style W, X, Y FACP NAC circuits is provided. In the event of a loop trouble, the FACP

will be notified via the steered input (input 1 or input 2). In addition, there are common trouble output terminals [NC, C,

NO] which are used to indicate general loop/system trouble. A common trouble input is provided for optional [NC] (nor-

mally closed) devices to report trouble to the FACP. Two (2) FACP signaling outputs can be employed and directed to

control supervision and power delivery to any combination of the four (4) outputs.

Specifications:

AL642ULADA - NAC Power Extender

WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.

This installation should be made by qualified service personnel and should conform to all local codes.
