Enclosure Dimensions for:
• ALTV244ULX
13"H x 13.5"W x 3.25"D
1.20”
1.40”
5.10”
5.10”
3.25”
1.00”
1.00” 10.50” 1.00”
1.00”
3.25”
3.25”
0.9375”
6.5625”
5.10”
1.40” 4.85” 4.85” 1.40”
3.25”
1.20”
0.75”
0.9375”
12.50”
11.00”
