- 6 -
XFMR
Black
Lead
non-power
limited
115VAC Input
50/60 Hz.
Green
Lead
(Ground)
White
Lead
Illuminated Power Disconnect
Circuit Breaker with manual reset
Class 1 Outputs
24VAC or 28VAC
output 1 (Follow
same procedure
using terminals
2P & N through
4P & N outputs
2 through 4)
Fig. 4
ALTV244175UL
INPUT
NP S
M
A
IN
F
U S
E
XFMR
Black
Lead
non-power
limited
115VAC Input
50/60 Hz.
Green
Lead
(Ground)
White
Lead
Illuminated Power Disconnect
Circuit Breaker with manual reset
24VAC configuration Class 2 Not Wet/Class 3 Wet
28VAC configuration Class 1
24VAC or 28VAC
output 1
(Follow same
procedure using
terminals 2P & N
through 4P & N
outputs 2 through 4)
Fig. 5
ALTV244175ULCB
Fig. 5A
Fig. 4A
