- 4 - SMP1012Xseries
INPUT
LED
PD4
POWER DISTRIBUTING UNIT
1P, 2P, 3P, 4P = FUSED OUTPUTS
1N, 2N, 3N, 4N = COMMON OUTPUTS
F1 F1 F2 F3 F4
COMMON POWER OUTPUTS
1P 1N 2P 2N 3P 3N 4P 4N
DC Output to devices From Power Supply
Board
(Factory Installed)
Used
on PTC
Models
PD8
N
COMMON POWER OUTPUTS
P
FUSED POWER OUTPUTS
1 2 3 4 5 6 7 8
1
D1
INPUT
R1
LED
DC Output to devices From Power Supply
Board
(Factory Installed)
Used
on PTC
Models
Fig. 3 Fig. 4
Power Distribution Module(s):
LED Diagnostics:
Power Supply Board
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC, Stand-by battery supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
PD4/PD4CB/PD8/PD8CB/PD16W/PD16WCB - Power Distribution Module
Green Power Distribution Module Status.
ON Normal operating condition.
3.5A 250V
For continuous protection against
risk of fire replace fuses with
same type and rating.
common
outputs
protected
outputs
P
N
N
P
S
XFMR Inpu
t
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
N
P
DC Output to devices
1P-16P Power Outputs,
1N-16N Common Outputs
) )
From Power
Supply
Board
(Factory
Installed)
1
Used
on PTC
Models
Fig. 5
