Smp1012x series - installation guide

background image

SMP1012Xseries

- 1 -

Overview:

These units will convert a 115VAC 50/60Hz input into a regulated 12VDC output at up to 10 amp continuous supply
current (see specifications).

SMP1012X Series Power Supply Configuration Reference Chart:

Altronix

Model Number

Accessory

Power

Distribution

Module(s)

Number of

Outputs

Fused Outputs

PTC Outputs

Output Rating (amp) per Output

Supervised

115VAC

50/60Hz Input

Current (amp)

12VDC Total

Output Current

(amp)

SMP10C12X

-

1

-

-

10

-

1.45

10

SMP10C12XX*

-

1

-

-

10

-

1.45

10

SMP10PMC12X

-

1

-

-

10

x

1.45

10

SMP10PMC12XX*

-

1

-

-

10

x

1.45

10

SMP10PM12P4

PD4

4

-

3.5

x

1.45

10

SMP10PM12P4CB

PD4CB

4

-

x

2.5

x

1.45

10

SMP10PM12P8

PD8

8

x

-

3.5

x

1.45

10

SMP10PM12P8CB

PD8CB

8

-

x

2.5

x

1.45

10

SMP10PM12P16

PD16W

16

x

-

3.5

x

1.45

10

SMP10PM12P16CB

PD16WCB

16

-

x

2.5

x

1.45

10

*Refer to Enclosure Dimensions on pg.7 for enclosure size.

Specifications:

Installation Instructions:

Wiring methods should be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI and with all local
codes and authorities having jurisdiction. Product is intended for indoor use only.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s
upper keyholes over the two upper screws; level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install three fasteners. Place the enclosure’s upper keyholes over the two
upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pgs. 6-7).
Secure enclosure to earth ground.
2. Connect AC power to the terminals marked [L & N].
Use 18 AWG or larger for all power connections (Battery, DC output).
3. Measure output voltage before connecting devices. This helps avoiding potential damage.

Battery Backup:

• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 0.7 amp.
• Filtered and electronically regulated outputs.
• Automatic switch over to stand-by battery when
AC fails (zero voltage drop).

Features:

• AC input and DC output LED indicators.

Features (cont’d):

• Short circuit and thermal overload protection.
• Complete with power supply, power distribution module
(when applicable), enclosure, cam lock & battery leads.
• Power ON/OFF switch.

Supervised models only:

• AC fail supervision (form “C” contacts).
• Low battery supervision (form “C” contacts).

SMP1012X Series - Installation Guide
