Power Supply/Chargers Operating Guide
Models Include:
Model
Input
120VAC, 60Hz
Output Auxiliary Power-Limited
Output (unswitched)
Ripple
Voltage 12VDC 24VDC
eFlow6N,
eFlow6N8, eFlow6N8D,
eFlow6N16, eFlow6N16D
3.5 amp 6 amp 6 amp 1 amp 910mV
eFlow6NX,
eFlow6NX8, eFlow6NX8D,
eFlow6NX16, eFlow6NX16D
Overview:
The eFlow6N series power supply/chargers convert a 120VAC, 60Hz input, to a 12VDC or 24VDC output.
Stand-by Specifications:
Battery
Burg. Applications
4 hr. Stand-by/15 min. Alarm
Fire Applications
24 hr. Stand-by/5 min. Alarm
Access Control
Applications Stand-by
7AH 0.4 amp/6 amp N/A 10 Mins./6 amp
12AH 1 amp/6 amp 0.3 amp/6 amp 25 Mins./6 amp
40AH 6 amp/6 amp 1.2 amp/6 amp Over 4 Hours/6 amp
65AH 6 amp/6 amp 1.5 amp/6 amp Over 4 Hours/6 amp
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 1.54 amp.
• Automatic switch over to stand-by battery when AC fails. Transfer to stand-by battery power is instantaneous
with no interruption.
LED Diagnostics:
Red (DC) Green (AC/AC1) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC, Stand-by battery supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
Installing Company: _________________________________ Service Rep. Name: ___________________________________________________
Address: _______________________________________________________________________ Phone #: _______________________________
Refer to the eFlow Power Supply/Chargers Installation Guide: IIeFlow6N Series, Rev. 6NRP052213 for complete
instructions. This sheet is to be removed, framed and posted next to the unit.
