Maximal11D/Maximal33D/Maximal55D/Maximal77D/Maximal75D Access Power Controllers (PTC)
- 3 -
MaximalD Series Overview:
Maximal Access Power/Controllers distribute and switch power to access control systems and accessories. They con-
vert a 115VAC 60Hz input into sixteen (16) independently controlled 12VDC or 24VDC Class 2 Rated PTC protected
power-limited outputs. These Fail-Safe/Fail-Secure power outputs may be converted to dry form “C” contacts. The outputs
are activated by an open collector sink or normally open (NO) dry trigger input from an Access Control System, Keypad,
Push Button, REX PIR, etc. Units will route power to a variety of access control hardware devices including: Mag Locks,
Electric Strikes, Magnetic Door Holders, etc. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may
be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any or all of the
sixteen (16) outputs. All interconnecting equipment must be UL Listed.
MaximalD Series Configuration Chart:
Altronix
Model
Number
Output Voltage Options
Total Output Current (16 outputs)
Current per ACM8CB Output
Class 2 Rated PTC
Protected Power Limited Outputs
115VAC 60 Hz Input (current)
Power Supply Board Input Fuse Rating
Power Supply Board Output Fuse Rating
Agency Listings and File Numbers
Power Supply 1 Power Supply 2
Maximal11D
AL400ULXB
AL400ULXB
------
2.5A
16
7A
5A/250V
15A/32V
UL File #
BP6714
UL 294
UL Listed
for
Access
Control
System
Units.
California
State
Fire Marshal
Approved
12VDC @ 3.5A 12VDC @ 3.5A
7A
12VDC @ 2.7A 24VDC @ 2.7A 5.4A
24VDC @ 3.5A 24VDC @ 2.7A 6.2A
Maximal33D
AL600ULXB
AL600ULXB
------
2.5A
16
7A
5A/250V
------
12VDC @ 5.5A 12VDC @ 5.5A 11A
12VDC @ 5.7A 24VDC @ 5.7A 11.4A
24VDC @ 5.5A 24VDC @ 5.7A 11.2A
Maximal55D
AL1012ULXB AL1012ULXB
19
2.5A
16
5.2A
5A/250V
15A/32V
12VDC @ 9.5A 12VDC @ 9.5A
Maximal75D
AL1012ULXB AL1024ULXB
19
2.5A
16
7.0A
5A/250V
(AL1012ULXB)
and
(AL1024ULXB)
15A/32V
(AL1012ULXB)
and
(AL1024ULXB)
12VDC @ 9.5A 24VDC @ 9.5A
Maximal77D
AL1024ULXB AL1024ULXB
19.4
2.5A
16
8.8A
5A/250V
15A/32V
24VDC @ 9.7A 24VDC @ 9.7A
MaximalD Series Features:
• Sixteen (16) independently trigger controlled outputs.
Output options:
a) Sixteen (16) Fail-Safe filtered and electronically regulated power outputs.
b) Sixteen (16) Fail-Secure filtered and electronically regulated power outputs.
c) Sixteen (16) form “C” relay outputs (rated @ 5 amp/28VDC or VAC).
d) Any combination of the above.
• Sixteen (16) Access Control System trigger inputs.
Input trigger options:
a) Sixteen (16) normally open (NO) dry trigger inputs.
b) Sixteen (16) open collector inputs.
c) Any combination of the above.
• Sixteen (16) unswitched filtered and electronically regulated aux. power outputs (outputs are rated @ 2 amp).
• ACM8CB maximum current is 2 amp per output.
