- 18 - Maximal11D/Maximal33D/Maximal55D/Maximal77D/Maximal75D Access Power Controllers (PTC)
Enclosure Dimensions (H x W x D) (approximate) :
26” (660.4mm) x 19” (482.6mm) x 6.25” (158.75mm)
TOP
LEFT RIGHT
BOTTOM
1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm) 0.85”
(21.59mm)
0.85”
(21.59mm)
1”
(25.4mm)
0.85”
(21.59mm)
1”
(25.4mm)
0.85”
(21.59mm)
8.9”
(226.06mm)
19”
(482.6mm)
19”
(482.6mm)
19”
(482.6mm)
2”
(50.8mm)
2”
(50.8mm)
2”
(50.8mm)
6.25”
(158.75mm)
6.25”
(158.75mm)
4”
(101.6mm)
4”
(101.6mm)
2”
(50.8mm)
4”
(101.6mm)
8.9”
(226.06mm)
8.4”
(213.36mm)
7”
(177.8mm)
7”
(177.8mm)
7”
(177.8mm)
8.4”
(213.36mm)
8.5”
(215.9mm)
8.5”
(215.9mm)
7.5”
(190.5mm)
10”
(254mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
26”
(660.4mm)
26”
(660.4mm)
7.5”
(190.5mm)
5”
(127mm)
26”
(660.4mm)
