- 6 - eFlow3N Series
Power Distribution Module(s):
Fig. 3a - PD4UL Power Distribution Board Fig. 3b - PD4ULCB - Power Distribution Board
LED
F1 F2 F3 F4
1P 1N 2P 2N 3P 3N 4P 4N
DC Output to devices
1P-4P Power Outputs,
1N-4N Common Outputs
) )
From Power Supply
Board
(Factory Installed)
Replace fuses with the same type and rating 3.5A, 250V.
INPUT
LED
F1 F2 F3 F4
POWER OUTPUTS
1P 1N 2P 2N 3P 3N 4P 4N
DC Output to devices
1P-4P Power Outputs,
1N-4N Common Outputs
From Power Supply
Board
(Factory Installed)
( )
