- 2 - eFlow3N Series
Overview:
The eFlow3N power supply/chargers convert a 120VAC / 60Hz input to a 12VDC or 24VDC nominal output
(see Power Supply Configuration Reference Chart and Specifications).
eFlow3N Series Power Supply Configuration Reference Chart:
Altronix Model Number
Nominal DC Outputs
Maximum Supply Current for Main and Aux. Outputs (amp) Power-Limited Output Input Rating: 120VAC, 60Hz Input Fuse Rating Battery Fuse Rating Ripple Voltage (mV) Under low battery condition Power Distribution Modiule Number of Outputs Fused Output Ratings PTC Output Ratings Accommodates up to 7AH Batteries Accommodates up to 12AH Batteries
[DC] [AUX]
12VDC Output Range (volts) 24VDC Output Range (volts) 12VDC Output Range (volts) 24VDC Output Range (volts)
eFlow3N
10.13-
13.2
20.28-
26.39
10.15-
13.2
20.2-
26.39
2A 3 3.5A 5A/250V 3A/32V 960 N/A 1
– – 3 –
eFlow3NX – – – 3
eFlow3N4
10.13-
13.2
20.28-
26.39
10.15-
13.2
20.2-
26.39
2A 3 3.5A 5A/250V 3A/32V 960 PD4UL 4
2A – 3 –
eFlow3NX4 2A – – 3
eFlow3N4D
9.78-
13.2
20.0-
26.39
10.15-
13.2
20.2-
26.39
2A 3 3.5A 5A/250V 3A/32V 960 PD4ULCB 4
– 2A 3 –
eFlow3NX4D – 2A – 3
These units are classified as Power-Limited stand alone power supplies with stand-by battery and they are suitable to power: sensors,
electro-mechanical devices (e.g. electric door strikes) defined in the National Electrical Code/NFPA70/NFPA72 and the Canadian
Electrical Code, Part 1.
Agency Listings:
UL Listings for US Installations:
UL 294 - UL Listed for Access Control System Units.
UL 603 - UL Listed for Power Supplies for Use with Burglar-Alarms Systems.
UL 1481 - UL Listed for Power Supplies for Fire Protective Signaling Systems.
UL Listings for Canadian Installations:
ULC-S318-96 - Power Supplies for Burglar Alarm Systems. Also suitable for Access Control.
California State Fire Marshal
(eFlow3N and eFlow3NX)
European Conformity
Stand-by Specifications:
Battery
Burg. Applications
4 hr. Stand-by/
15 min. Alarm
Fire Applications
24 hr. Stand-by/
5 min. Alarm
Access Control
Applications
Stand-by
7AH 0.4 amp/2 amp N/A 1.5 Hours/2 amp
12AH 1 amp/2 amp 0.3 amp/2 amp 3.5 Hours/2 amp
40AH (for eFlow3NX refer to Fig. 7, pg. 10) 2 amp/2 amp 1.2 amp/2 amp Over 4 Hours/2 amp
65AH (for eFlow3NX refer to Fig. 7, pg. 10) 2 amp/2 amp 1.5 amp/2 amp Over 4 Hours/2 amp
