CUT ALONG DOTTED LINE
Power Supply/Chargers Operating Guide
Models Include:
Model
Input
120VAC, 60Hz
Output Power-
Limited
Auxiliary Power-Limited
Output (unswitched)
Ripple
Voltage 12VDC 24VDC
eFlow3N,
eFlow3N4,
eFlow3N4D
3.5 amp 2 amp 2 amp 3 1 amp 960mV
eFlow3NX,
eFlow3NX4,
eFlow3NX4D
Overview:
The eFlow3N series power supply/chargers convert a 120VAC, 60Hz input, to a 12VDC or 24VDC output.
Stand-by Specifications:
Battery
Burg. Applications
4 hr. Stand-by/15 min. Alarm
Fire Applications
24 hr. Stand-by/5 min. Alarm
Access Control
Applications Stand-by
7AH 0.4 amp/2 amp N/A 1.5 Hours/2 amp
12AH 1 amp/2 amp 0.3 amp/2 amp 3.5 Hours/2 amp
40AH 2 amp/2 amp 1.2 amp/2 amp Over 4 Hours/2 amp
65AH 2 amp/2 amp 1.5 amp/2 amp Over 4 Hours/2 amp
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 1.54 amp.
• Automatic switch over to stand-by battery when AC fails. Transfer to stand-by battery power is instantaneous
with no interruption.
LED Diagnostics:
Red (DC) Green (AC/AC1) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC, Stand-by battery supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
Installing Company: _________________________________ Service Rep. Name: ___________________________________________________
Address: _______________________________________________________________________ Phone #: _______________________________
Refer to the eFlow Power Supply/Chargers Installation Guide: IIeFlow3N Series, Rev. 3NRP052213 for complete
instructions. This sheet is to be removed, framed and posted next to the unit.
Rev. 3NRP052213
