IIeBridge1PCRMT
C21M MEMBER
Maximum Length of Coax Type vs. Camera Power/PoE Class:
Camera
Power/
PoE Class
Coax Type
RG59/U - 23AWG RG59/U - 22AWG RG59/U - 20AWG RG59/U - 18AWG RG6/U - 18AWG
Max. Length (ft./meters)
13W/0 855/260.64 1,100/335.28 1,500+/457.20+ 1,500+/457.20+ 1,500+/457.20+
4W/1 1,500+/457.20+ 1,500+/457.20+ 1,500+/457.20+ 1,500+/457.20+ 1,500+/457.20+
6.5W/2 1,500+/457.20+ 1,500+/457.20+ 1,500+/457.20+ 1,500+/457.20+ 1,500+/457.20+
13W/3 855/260.64 1,100/335.28 1,500+/457.20+ 1,500+/457.20+ 1,500+/457.20+
19W 500/260.64 650/335.28 1035/457.20+ 1,500/457.20+ 1,500/457.20+
25W 390/260.64 494/335.28 785/457.20+ 1,200/457.20+ 1,200/457.20+
Notes:
