eBridge1PCRMT
- 1 -
PLUS
Overview:
The eBridge1PCRM and eBridge1PCTX are CAT5 to Coax cable Ethernet adapters/Media converters that deliver data
and power over the coax cable in a PoE+ compliant format. The paired set enables fast 10/100Base-T Ethernet digital
communication to be transmitted over Coax cable. An eBridge1PCRM receiver is powered by a PoE midspan or endspan
product, such as a NetWay8M and NetWay16M and sends its power over the coax to the eBridge1PCTX transmitter under
PoE protocol. This enables the eBridge1PCRM to be used in a managed manner, allowing for remote camera reset. The
eBridge1PCTX in turn delivers that PoE+ compliant power to a PoE enabled camera or IP device. The eBridge1PCRM will
not deliver power to non compliant devices, thus avoiding damage to improperly connected analog cameras. These plug
and play units facilitate system upgrades from analog to IP cameras/devices utilizing existing legacy Coax and eliminating
the costs and labor associated with installing new network cabling. In addition, data transmission and power over the Coax
is possible up to1500 ft. in comparison to 100m (328 ft.) Ethernet maximum distance (see Maximum Length of Coax Type
vs. Camera Power/PoE Class, pg. 3). A maximum range from head end to the PoE camera/device is 610m (2000 ft.) taking
into consideration that up to 100m (328 ft.) of structured cable may be deployed at each end.
Features:
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
• C-Tick compliant.
Compliant:
• Incorporates *sloc
TM
(Security Link over Coax) technology.
Input:
• Powered by midspan or endspan.
Local Aux. Input Power for eBridge1PCRM:
• 24VDC/110mA or 24VAC/200mA.
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5 or better structured cable.
• Distance: up to 100m (328 ft.).
• Speed: 10/100BaseT, half/full duplex, auto negotiation.
PoE compliant to IEEE 802.3af (15W) and PoE+
compliant to IEEE 802.3at (30W) Delivered to
camera by eBridge1PCTX. Power provided by
eBridge1PCRM to eBridge1PCTX by PoE protocol.
• Throughput is rated to pass 25mbps of data at
distances up to 1500 ft. With proper headend
equipment, this supports Megapixel, HD720, HD1080.
Coax:
• Distance: up to 1,500 ft. (see Maximum Length of Coax
Type vs. Camera Power/PoE Class, pg. 3) for power
delivery of coax.
• Connectivity: BNC, RG-59/U or similar.
LED Indicators:
• eBridge1PCRM:
Blue LED - Coax link connection (sloc).
Green - PoE ON.
Green - Power ON.
LED Indicators (cont’d):
• eBridge1PCRM and eBridge1PCTX:
Yellow and Green LED (RJ45) IP Link status,
10/100Base-T/active.
• eBridge1PCTX:
Blue LED - Coax link connection (SLOC).
Green LED - PoE from eBridge1PCRM.
Environmental:
•
Operating Temperature:
eBridge1PCRM:
-- 4ºF to 140ºF (-- 20ºC to +60ºC).
eBridge1PCTX: --- 4ºF to 140ºF (-- 20ºC to +60ºC).
•
Storage Temperature:
-- 22º to 158ºF (-- 30º to +70ºC) Storage.
• Humidity: 20 to 85%, non-condensing
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Retrofit digital IP cameras in an analog CCTV
installation.
• Works with Megapixel, HD720, HD1080 and VGA
(SD) cameras (see note, pg. 2).
• Extend Network link distance in an industrial
environment over 610m (2000 ft.) (see note, pg. 2).
• Upgrade deployed CCTV Coax to a digital network
in Retail, Casinos, Airports, Schools, Hospitals, etc.
Mechanical:
• Dimensions (W x L x H approx.):
eBridge1PCRM:
3.5” (88.89mm) x 4.375” (111.125mm) x 1” (25.4mm)
eBridge1PCTX:
2.5” (63.5mm) x 4.375” (111.125mm) x 1” (25.4mm)
eBridge1PCRMT - IP and PoE+ over Coax Solution
eBridge1PCRM Receiver and eBridge1PCTX Transceiver kit
Installation Guide
Rev. 032113
I.T.E. 43KC
Z1409
* sloc is a registered trademark of Intersil Corporation.
