Antenna impedance cone PEEK -1 … 100 bar (-100 … 10000 kPa/-14.5 … 1450 psig)
-
Antenna impedance cone ceramic -1 … 160 bar (-100 … 16000 kPa/-14.5 … 2320 psig)
Vessel pressure - parabolic antenna -1 … 6 bar (-100 … 6000 kPa/-14.5 … 870 psig)
Vessel pressure relating to the flange nom-
inal stage see supplementary instructions manual "Flanges
according to DIN-EN-ASME-JIS"
Vibration resistance
-
Horn antenna 4 g at 5 … 200 Hz according to EN60068-2-6
(vibration with resonance)
-
Parabolic antenna 1 g at 5 … 200 Hz according to EN60068-2-6
(vibration with resonance)
Shock resistance
-
Horn antenna 100 g, 6 ms according to EN60068-2-27 (mechan-
ical shock)
-
Parabolic antenna 25 g, 6 ms according to EN60068-2-27 (mechanical
shock)
Data on rinsing air connection
Pressure max. 6 bar (87.02 psig)
Air quantity without reflux valve, with
-
0.2 bar (2.9 psig) 2.0 m 3
/h
-
0.5 bar (7.25 psig) 3.5 m 3
/h
-
1 bar (14.5 psig) 4.5 m 3
/h
-
1.5 bar (21.76 psig) 5 m 3
/h
-
2 bar (29.0 psig) 5.5 m 3
/h
Thread G⅛ A
Closure, with
-
Non-Ex Dust protection cover of PE
-
Ex Threaded plug of 316Ti
Reflux valve - unmounted (as option with non-Ex version, included in the scope of delivery with Ex
version)
-
Material 316Ti
-
Seal FKM (Viton), FFKM (Kalrez 6375)
-
for tube diameter 6 mm
-
opening pressure 0.5 bar (7.25 psig)
-
Nominal pressure stage PN 250
Electromechanical data - version IP 66/IP 67 and IP 66/IP 68; 0.2 bar
Cable entry/plug 7)
-
Single chamber housing l
1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5
7) Depending on the version M12 x 1, according to ISO 4400, Harting, 7/8" FF.
