42
Installation option - converting from desktop to wall mount position
To mount the telephone base on the wall:
Set aside the handset. On the telephone base cradle, place a coin in the slit of the wall mount clip and rotate a half turn
(180 degrees). It locks into place with the protruding edge pointing towards the upper edge of the telephone base. This
protruding edge holds the handset when the phone is mounted on the wall.
Turn the telephone base over with the bottom side facing up. To remove the mounting bracket, firmly push both tabs downward
and pull up until both tabs release from the grooves.
Mount the telephone base on th e wall by aligning the eyelets with the mounting studs of the wall plate. Th en slide the telephone
base down on both mounting studs until it locks into place.
Place the handset on the telephone base cradle.
1.
2.
3.
4.
Protruding edge
Mounting
bracket
Eyelets
Analog corded/cordless 1-line - CTM-A2510
Installation
