Telephone layout
Analog cordless 2-line - CTM-A2421/CTM-A2421-BATT
MESSAGE WAITING LED
CHARGE LED
LINE 1 LINE 2 CONF
MESSAGE WAITING LED
Wall mount clip
/FIND HANDSET
HOLD
MUTE
FLASH
REDIAL
PROGRAM (recessed key)
PAUSE (recessed key)
Speed Dial keys
DATA port
/SPEAKER
Speed Dial key
-/VOLUME
+/VOLUME
LINE 1
REDIAL
HOLD
OFF
FLASH
MESSAGES
MUTE
-/VOLUME/+
/SPEAKER
LOW BATTERY LED
Speed Dial keys
CONF
LINE 2
