Security Printing Solutions

Quick-Start Guide

Document #50-70436-001 Rev. C

Page 7 of 13

8. Repeat Steps 5 through 7 to install the barcode screen fonts. Double-click on the Support Files folder,

double-click on the HPD Files folder, and then double-click on the Barcode folder. Within the List of
Fonts
section, click on Select All to highlight all available barcode fonts, and then click on OK. A
processing window may appear while the installation process proceeds.

9. Close all remaining open windows. The TROY screen fonts are now installed.

NOTE: For International customers, the International numeric fonts are not resident on the TROY

Memory Card. These fonts are located on the TROY Security Printing Solutions CD in the
“\Support Files\HPD Files\International\Fonts” folder and can be added to the TROY Memory
Card using the TROY Printer Utility – Download Soft Fonts Option. These fonts are designed
as non-scalable bitmapped fonts.

Install the TROY Metrics File for Windows

2000, XP, Vista, 7 Server 2003,

and Server 2008 Operating Systems

1. Close all applications before installing the TROY Font support files.

2. If you have the TROY Security Printing Solutions CD, insert it into your computer’s CD drive,

otherwise you will need to download the MICR Support Files from:

http://www.troygroup.com/support/downloads/MICR_Support_Files(PCM).exe

.

3. In order for the OS to be able to permanently load the fonts to the printer, the PCM Files directory

needs to be placed at the root of the C: drive. Copy the %TROYCD%\Font Support Files\PCM Files

directory to the root of the C: drive if you have the TROY CD, otherwise extract the downloaded files to

the root of the C: drive.

4. From the Start menu, click on Control Panel, and then double-click on Printers.

5. Right-click on the TROY Printer that was installed, and then click on Printer Properties from the menu.

6. Click on the Device Settings tab located at the top of the Properties window.

7. Click on External Fonts (under the Font Substitution Table category), and then click on the Properties

button.

8. Click on the Browse button to open the drive selection window.

9. Expand the C: drive, double-click on the PCM Files folder, click on the Domestic folder, and then click

on OK to close the drive selection window. For international products, click on the International folder.

10. Use the SHIFT key to select all the fonts located in the left-hand window named TROY Auto-Protect,

TROY CMC7, etc., and then click on Add to add those fonts. If you want to add an individual font, just

highlight that specific font name and click on the Add button. All the added fonts should be displayed in

the right-hand window.

NOTE: If you need to install the Barcode fonts, repeat Steps 8 through 10 but browse to the Barcode folder instead

of Domestic.

11. Close all remaining open windows. Please refer to the TROY Security Printing Solutions User’s Guide,

Section 7 – Using TROY Fonts before using the installed fonts.

NOTE: Windows 2000, XP, Server 2003, Vista, 7 and Server 2008 do not require installation of the TROY

screen fonts.
