Security Printing Solutions

Quick-Start Guide

Document #50-70436-001 Rev. C

Page 6 of 13

9. Click on the Browse button to open a Windows Explorer-style window. Click on the down-arrow in the

Drives box to select the CD-ROM drive on your computer. Double-click on the Support Files folder
from the list of folders, double-click on the HPD Files folder, and then double-click on the Domestic
folder. For international products, double-click on the International folder.

10. Click on the file (located in the left-hand window) named TroySEC.hpd or TroySECINTL.hpd (for

International customers), and then click on Open or OK (the displayed window may vary depending on
the operating system being used). With some printer drivers, the Add Font Card window will appear.
If this window appears, click on OK to close the window.

11. Within the Configure Font Cards window, verify the installation by clicking on the Font Card Name:

TROY Security Font Collection or TROY International Security Font Collection listed under Installed
Font Cards
. Within the Fonts list, the TROY E-13B (enabled) along with other TROY fonts will be
displayed.

12. Repeat Steps 9 through 11 to install the barcode fonts. Double-click on the Support Files folder, the

HPD Files folder, and the Barcode folder, and then select the TroyBAR.hpd file. Verify the installation
by clicking on the Font Card Name: TROY Barcode Font Collection listed under Installed Font Cards.
Within the Fonts list, the TROY barcode fonts will be displayed.

13. Close all remaining open windows. Please refer to the TROY Security Printing Solutions User’s Guide,

Section 7 – Using TROY Fonts before using the installed fonts.

Install the TROY Screen Fonts for Windows

98SE and ME Operating Systems

In addition to the TROY printer fonts that are permanently programmed into your TROY Security Printing
Solution, the TROY screen fonts have been developed for display use only as a visual reference and for
making positional adjustments to the MICR line. The TROY screen fonts display differently than the actual
printer fonts to prevent unauthorized printing using the MICR screen fonts on other Windows-installed
printers.

If the E-13B MICR screen font is used for printing, the inversely printed (white characters on black
background) MICR screen font will not be readable by the bank reader/sorter machines. The uniquely
displayed screen fonts ensure that the MICR font printed on your MICR documents is generated from a
TROY Security Printing Solution and not from the Windows TrueType

screen font. The TROY screen

fonts are provided on the TROY Security Printing Solutions CD supplied with your TROY Security
Printing Solution.

NOTE: Windows 2000/XP operating systems do not require installation of the TROY screen fonts.

1. Close all applications before installing the TROY support files.

2. Insert the TROY Security Printing Solutions CD into your computer CD-ROM drive.

3. From the Start menu, click on Settings, and then click on Control Panel.

4. Double-click on the Fonts folder icon.

5. Click on File, and then click on Install New Font… A new window labeled Add Fonts will open and

then a Windows Explorer-style window will open.

6. Click on the down-arrow in the Drives box to select the CD-ROM drive on your computer. Double-

click on the Support Files folder from the list of folders, double-click on the HPD Files folder, and then
double-click on the Domestic folder. For international products, double-click on the International
folder.

7. A list of TROY fonts will be listed within the List of Fonts section. Click on Select All to highlight all

available fonts, and then click on OK. A processing window may appear while the installation process
proceeds. Individual fonts may be selected if all the fonts are not needed.
