40
Gear & Pinion Kits
Gear & Pinion Kits
R - Rear Axle - Standard Applications
R344/404/405/454, 17060/19060/21060/22060S/D/L
15.4”-15.7” Hypoid
Spline: 39-1.95” Involute
Pinion Nut Part-No 127589
Spicer Current Current Original Original Original
Ratios Kit Gear (NSS) Pinion (NSS) Kit Gear (NSS) Pinion (NSS)
2.64 211478 127380 (37) 127420 (14) NA NA NA
2.85 211479 127381 (37) 127421 (10) NA NA NA
2.93 509424 129534 (41) 129533 (14) NA NA NA
3.08 513373 127381 (37) 139737 (12) 211480 127381 (37) 127422 (12)
3.25 513372 127382 (39) 130127 (12) 211481 127382 (39) 127423 (12)
3.36 513371 127381 (37) 130128 (11) 211482 127381 (37) 127424 (11)
3.42 504055 134325 (41) 134326 (12) NA NA NA
3.55* 513370 127382 (39) 130129 (11) 211483 127382 (39) 127425 (11)
3.70 513369 127381 (37) 130130 (10) 211484 127381 (37) 127426 (10)
3.90 513368 127382 (39) 130131 (10) 211485 127382 (39) 127427 (10)
4.11* 513367 127381 (37) 130132 (9) 211486 127381 (37) 127428 (9)
4.33 513366 130200 (39) 130133 (9) 211487 127382 (39) 127429 (9)
4.63 513365 130194 (37) 129748 (8) 211488 127383 (37) 127430 (8)
4.88 513364 130195 (39) 129750 (8) 211489 127384 (39) 127431 (8)
5.29 513363 130194 (37) 129818 (7) 211490 127383 (37) 127432 (7)
5.57 513362 130195 (39) 129822 (7) 211491 127384 (39) 127433 (7)
6.17 513361 127383 (37) 129844 (6) 211492 127383 (37) 127434 (6)
6.50 211493 127384 (39) 127435 (6) NA NA NA
7.17 211494 127385 (43) 127436 (6) NA NA NA
NSS – Not Sold Separately
Note: In mid-2004, the original design gearing kits were replaced by new gearing that contain design enhancements. In some cases when changing
certain ratios
(*ratios affected) or using new design gearing kits to replace original gearing, a differential flange half case change may be required. All
flange half differential cases are now available thru Spicer as individual components.
Spicer offers new highly developed Gen-Tech™ quiet gearing for single axle applications that require low noise resolution while maintaining the same
high strength quality that Spicer
® genuine gearing is known for. This gearing like all Spicer gearing is developed and machined in sets and specified by
many customers in medium duty applications. Never mix gears and pinions from different sets within an axle. Shortened gearing life, noise and failure
may occur. When replacing gearing check the drive pinion and ring gear numbers to the charts below to get the correct replacement service kit.
