30
Output Shaft and Axle Housings
Output Shaft and Axle Housings
Item Description Qty Part No. Notes
1 Axle Shaft 2 Axle Shaft Chart page 34
2 Outer Bearing Adjuster Nut 2 119881 See Note 2
3 Lockwasher - w/Tab 2 129132
4 Dowel-Type Lockwasher 2 119883
5 Inner Bearing Adjuster Nut 2 119882
6 Axle Housing Assy 1 Note: See page 36 See your OEM Catalog
7 U-Tube Breather Kit 1 507162 Contains items: 129340 & 302706
8 Magnetic Drain Plug - 3/4” 1 054254 All D/R models
9 Stud - Carrier to Hsg 4 127641 All D/R models M16 X 1.5
10 Washer - Carrier to Hsg 12 029804 All D models
10A Washer - Carrier to Hsg 4 029804 All R models
11 Nut - Carrier to Hsg 4 127567 All R models
12 Capscrew - Carrier to Hsg 10 130836 All D/R models (was 210173 and 130158)
M16 X 2.0
13 Axle Hsg Cover Kit 1 217519-NLA Includes 13, 15-16, 23-29
Cover casting #127486C NSS Replaces 129490/127487/129489/129037
Refer to note 13 below Ref: Bulletin ABIB-9709
14 Capscrew - Hsg Cover to Hsg 8 210135 M12 x 1.75
15 Magnetic Plug - 1” 1 075130 See Bulletin ABIB-9709
15 Non-Magnetic Plug 3/4” 1 129492 See Bulletin ABIB-9709
15 Magnetic Plug - 3/4” 1 129491 See Bulletin ABIB-9709
16 Temperature Sensor Plug 1/2” 1 090898
17 Lube Tag (for 3/4” Plug) 1 129486 See Bulletin ABIB-9709, Part - Not Illustrated
17 Lube Tag (for 1” Plug) 1 128288 See Bulletin ABIB-9709, Part - Not Illustrated
18 Nut - Hsg Cover to Hsg 4 127569 All Forward Axles
19 Lockwasher - Hsg Cover to Hsg 4 210140 All Forward Axles
20 Stud - Hsg Cover 4 127568 All Forward Axles
21 Dowel Pin - Hsg Cover 1 007641 All Forward Axles
OUTPUT SHAFT KIT 1 216227 Includes Items 22-23
22 Output Shaft - #127646 NSS
23 Locknut – Hex 1 127588 M39 x 1.5
24 Oil Seal 1 127592•*
25 Snap Ring .103” 1 129594•* Replaces 127538, 127537
26 Bearing Cup 2 127539•*
27 Bearing Cone 2 127540•*
28 Seal Driver 1 126917 In Kit 217414
29 Adapter 1 128706 In Kit 217414
30 Loctite Adhesive 1 129293 Not Illustrated, .5 ml Tube
31 RTV - Sealant 1 107276S Not Illustrated, 3 oz. Tube
NSS - Not Sold Separately
NOTE 2: All 404/405/454 models except 344. Use p/n 19186, 30714 for D/R344 series.
NOTE 13: In the 4th qtr of 1998 a design change was made to the FORWARD axle housings in the 404 family axles. The axle housing rear cover is no
longer a bolt on cover but is a welded assembly. The bolt up cover are no longer manufactured or offered by Dana.
• included in basic overhaul kit
* included in bearing kit
