Spicer IPL: 454 Tandem Drive Axle - Manual (Page 29)

28
In Axle Speed Sensor
In Axle Speed Sensor
DA344 RA344 DA344 RA344
DA404-(P) RA404 DA404-(P) RA404
DA405-(P) RA405 RA405-(P) RA405
DA454-P RA454 DA454-P RA454
Item Description Qty (Before 11-2-98) (Before 11-2-98) (After 11-2-98) (After 11-2-98) Notes
1 Sensor Connector 2 128713 128713 ––– ––– See Note below
2 Diff Bearing Adjusters
Plain Half - 344 series 1 129056-NLA 129056-NLA 129056-NLA 129056-NLA See Note below
Flange Half - 344 series 1 129055-NLA 129055-NLA 129055-NLA 129055-NLA See Note below
Plain Half - 404/405/454 1 128429 -NLA 128429 -NLA 128429 -NLA 128429 -NLA See Note below
Flange Half - 404/405/454 1 128428 -NLA 128428 -NLA 128428 -NLA 128428 -NLA See Note below
3 Rotor Assembly
41 spline 2 128081 -NLA 128081 -NLA 128081 -NLA 128081 -NLA All models except D/R344
39 spline 2 128993 -NLA 128993 -NLA 128993 -NLA 128993 -NLA D/R344 models only
4 Sensor Assembly 2 128082 -NLA 128082 -NLA 128082 -NLA 128082 -NLA See Note below
5 Fasteners 4 128074 -NLA 128074 -NLA 128074 -NLA 128074 -NLA See Note below
6 Sensor Connector Assy 2 ––– ––– 129061 -NLA 129061 -NLA Includes Item 7 - see note below
7 O-ring 2 ––– ––– 14033 14033 See Note below
8 Bushing Sleeve 2 ––– ––– 129059 -NLA 129059 -NLA See Note below
9 Snap Ring 2 ––– ––– 129057 -NLA 129057 -NLA See Note below
NOTE Some IASS model parts are no longer manufactured or available and stock availability of individual items are limited. If key components for these models
are not available, retrofitting the vehicle and ABS systems to more conventional system set up will be required. Consult your OEM for engineering help.
