Spicer IPL: 454 Tandem Drive Axle - Manual (Page 16)

15
Before June 2008
DA344
DS344
DA404(P)
DS404(P)
DA405(P) DA454(P) DD404(P)
Item Description Qty DS405(P) DS454(P) DD405(P) DD454(P) Notes
RING GEAR NUT & BOLT KIT 508652 508652 508652 508652 Includes items 20-21
20 Nut 16 126216 126216 126216 126216
21 Bolt 16 129686 129686 129686 129686 129686 Replaces 128806
See bulletin ABIB-9701
22 Pinion Pilot Brg 1 127484•* 127484•* 127484•* 127484•*
23 Pinion Brg Cone - Inner 1 129560•* 129560•* 129560•* 129560•* 129560 Replaces 85439
24 Pinion Brg Spacer (Svc Kit) AR 504043 504043 504043 504043 Individual Pinion Bearing Spacers
Listed on page 11
25 Pinion Brg Cage & Cup Assy 1 129767 129767 129767 129767 Includes item 25-27
Cage #127488C NSS 129767 Replaces 127601
26 Pinion Brg Cup - Inner 1 129561•* 129561•* 129561•* 129561•* 129561 Replaces 14217
27 Pinion Brg Cup - Outer 1 012495•* 012495•* 012495•* 012495•*
28 Pinion Brg Cone - Outer 1 127535•* 127535•* 127535•* 127535•*
29 Capscrew 6 210115 210115 210115 210115
30 Pinion Helical Gear 1 127523 127523 127523 127523
31 Roll Pin 1 118807 118807 118807 118807
32 Slotted Pinion Nut 1 126182 126182 126182 126182
34 Output Shaft Brg Cup 1 127536•* 127536•* 127536•* 127536•*
35 Output Shaft Brg Cone 1 110812•* 110812•* 110812•* 110812•*
36 Output Shaft Side Gear 1 127645 127645 127645 127645
37 Snap Ring 1 085997• 085997• 085997• 085997•
38 Inter-Axle Diff Assy 1 134192 134192 134192 134192 134192 replaces 128634, 129771
39 Helical Side Gear & Bushing 1 130907 130907 130907 130907 Was 127495 and 127494 - See
Assy Gear #130906 NSS Note 39; Includes Item 40
40 Bushing - Helical Gear 2 129371 129371 129371 129371 129371 Replaces 127543
41 Thrust Washer - Helical Gear 1 132439• 132439• 132439• 132439• 132439 replaces 128702
42 Lockout Sliding Clutch 1 127510 127510 127510 127510
43 Input Shaft Kit 1 510593 510593 510593 510593 Includes Items 41, 43, 58
shaft#129770-NSS (was 128704) Was 216226 - See Note 43
44 Oil Retainer 1 128700 128700 128700 128700
45 Input Shaft Bearing Cone 1 129558•* 129558•* 129558•* 129558•* 129558 Replaces 820643
For Items 46 through 49, See page 20
50 Bearing Cup 1 1008912•* 1008912•* 1008912•* 1008912•* Can use 129559
NOTE 39: Helical Gear part numbers 127495 & 130907 are totally interchangeable. The 130907 is an enhanced design and 127495 is no longer being
produced. No other associated parts are affected by this change. These parts are used in ALL D404 family axles.
NOTE 43: Kit 510593 replaces kit 216226 in all situations. But kit 216226 cannot replace kit 510593 in the following specific models DSH40(P), DDH40(P),
DSH44(P), and DDH44(P) unless it contains shaft number 129770. Kit 510593 contains input shaft p/n 129770, which is Induction Hardened for those
model applications. Input shaft p/n 128704, which is NOT Induction Hardened, was originally included in kit 216226 up to April 22, 2003. Beginning April
22, 2003 Dana began using induction hardened input shaft 129770 in place of 128704.
Single Reduction-Forward Axles
