Pinion Bearing Spacers
Pinion Bearing Spacers
D344/404(P)/405(P)/454(P)
PINION BRG SPACER KIT: 504043 (includes items w/*)
New Spacers
Spacer Thickness
129079
0.797
129080
0.798
129081
0.800
129082
0.801
129083
0.802
129084
0.803
129085
0.804
129086*
0.806
129087
0.807
129088
0.808
129089
0.809
129090*
0.810
129091
0.811
129093
0.812
129097
0.814
129099*
0.815
129101
0.816
129103*
0.817
129105
0.818
129107
0.819
129109*
0.820
129111
0.821
129113
0.822
129115
0.823
129117*
0.824
129119
0.825
129120*
0.826
129121
0.828
129122
0.829
129123
0.830
129124*
0.831
129125
0.832
129126
0.833
R344/404/405/454, 17/19/21/22060
PINION BRG SPACER KIT: 504016 (includes items w/*)
Bearing Spacers Part Number
Spacer Thickness
91552*
0.623
91553
0.624
91554
0.625
91555
0.626
91556*
0.627
91557
0.628
91558
0.629
91559*
0.630
91560
0.631
91561
0.632
91562
0.633
91564
0.634
91566
0.635
91568
0.636
91572*
0.637
91576
0.638
91580*
0.639
91584
0.640
91588
0.641
91592
0.642
91596*
0.643
91600
0.644
91602*
0.645
91604
0.646
91606
0.647
91608
0.648
91610
0.649
91611
0.650
91612
0.651
91613
0.652
91614*
0.653
91615
0.654
Note March 1 1995, Spicer D344/404/405/454 series axles were built with a thicker variable pinion spacer different from the original design, axles
built before this date used a “two” washer setup. This “two” washer setup is comprised of a spacer washer (127565) and a variable pinion bearing spacer
(part number by thickness).
When servicing the above models, select a variable pinion bearing spacer from the list below to attain the correct pinion bearing preload. All procedures
on “Pinion Bearing Preload” remain the same and the proper steps should be followed according to your Spicer Service Manual. If you have an
existing 127565 spacer washer, do not use it with the new variable pinion bearing spacers listed below.
Spacer washer 127565 is no longer available and has been removed from all service kits. The current variable pinion bearing spacers listed above are
sold separately or available in listed pinion bearing spacer kit.
