Axle Shafts by Spline Count
Axle Shafts by Spline Count
BODY LENGTH
BOLT HOLE TYPE:
S=Straight
T=Tapered
SPLINE TYPE:
STR=Straight
INV=Involute
A=Angular
BODY O.D.
SPLINE O.D.
NUMBER OF SPLINES
210512
PART NUMBER
FLANGE TYPE:
F=Flathead
B=Bell
BOLT CIRCLE
36 Spline
Body Spline
Flange
Bolt
Part No.
Length Diameter O.D.
O.D.
Circle
No.
Hole
(in)
(in)
(in)
(in)
(in)
Holes
Type
Notes
128375
40.906
1.75
1.85
6.13
5.25
12
781-TPR
210654
40.906
1.81
1.85
6.13
5.25
12
781-TPR
132824
41.000
1.61
1.85
6.08
5.22
8
485-STR
110890
41.063
2.00
2.31
8.50
7.00
8
948-TPR
134074
41.150
1.61
1.85
6.63
5.50
8
635-STR
134231
41.150
1.61
1.85
6.22
5.25
12
781-TPR
126965
41.313
2.25
2.31
8.50
7.00
8
948-TPR
128400
41.313
2.25
2.31
8.50
7.00
8
773-STR
128599
41.313
2.25
2.31
8.50
7.24
8
948-TPR
129513
41.313
2.25
2.31
8.50
7.00
8
948-TPR Diff lock shaft with 11.50” spline
129515
41.313
2.25
2.31
8.50
7.00
8
635-STR Diff lock shaft with 11.50” spline
129516
41.313
2.25
2.31
8.50
7.00
8
773-STR Diff lock shaft with 11.50” spline
129138
41.375
2.06
2.31
8.50
7.00
8
948-TPR Diff lock shaft with 11.00” spline
129142
41.375
2.06
2.31
8.50
7.00
8
773-STR Diff lock shaft with 11.00” spline
129507
41.375
2.06
2.31
8.50
7.00
8
948-TPR
129597
41.375
2.06
2.31
8.50
7.00
8
773-STR
126958
42.000
2.06
2.31
8.50
7.00
8
948-TPR
129960
42.000
2.06
2.31
8.50
7.00
8
773-STR
134235
42.205
1.61
1.85
6.22
5.31
8
781-TPR
129520
42.216
2.25
2.31
8.50
7.00
8
948-TPR Diff lock shaft with 11.50” spline
129522
42.216
2.25
2.31
8.50
7.00
8
635-STR Diff lock shaft with 11.50” spline
128975
42.500
2.06
2.31
8.50
7.24
8
948-TPR
130213HX
42.500
2.06
2.31
8.50
7.00
8
948-TPR
119409
42.750
2.25
2.31
8.50
7.00
8
948-TPR
126804
42.750
2.25
2.31
8.50
7.24
8
948-TPR
129954
42.750
2.06
2.31
8.50
7.00
8
948-TPR
128468
43.500
2.25
2.31
8.50
7.00
8
948-TPR
126197
43.750
2.25
2.31
8.50
7.24
8
948-TPR
129511
43.750
2.25
2.31
8.50
7.24
8
948-TPR Diff lock shaft with 11.50” spline
129585
43.750
2.25
2.31
8.50
7.00
8
948-TPR Diff lock shaft with 11.50” spline
360SR112-1 43.952
1.72
1.85
6.08
5.22
8
485-STR
