Axle shafts by part number – Spicer Drive Axles Illustrated Parts List Axle Shafts & Wheel End Parts User Manual
Page 15
13
Axle Shafts by Part Number
BODY
SPLINE
FLANGE
Bolt
Part
Length Dia. O.D. Flange O.D.
Circle
No.
Hole
Diff Lock
No.
Model
(in)
(in) Type No.
(in)
Type
(in)
(in)
Holes
Type
Spline
130523
S110, S110L
39.290 1.56 I
34 1.75
F
6.08
5.22
8
485-STR
130524
S110, S110L
41.000 1.56 I
34 1.75
F
6.08
5.22
8
485-STR
130610
S110
37.480 1.56 I
34 1.75
F
6.19
5.22
8
590-STR
130611
S110
39.173 1.56 I
34 1.75
F
6.19
5.22
8
590-STR
130757
S110
41.653 1.56 I
34 1.75
F
6.08
5.22
8
485-STR
130758
S110, S111
38.642 1.56 I
34 1.75
F
6.08
5.22
8
485-STR
130911
17060S, 19060S, D/R344
42.875 1.81 I
39 2.00
F
6.63
5.50
8
645-STR
130912
17060S, 19060S, D/R344
38.688 1.81 I
39 2.00
F
6.63
5.50
8
645-STR
130963
D/R451
44.380 1.87 I
41 2.11
B
8.50
7.00
8
948-TPR
131245
D/R170, D/R190
46.000 2.25 I
46 2.35
B
8.50
7.00
8
948-TPR 11.50”
131246
D/R170, D/R190
37.000 2.25 I
46 2.35
B
8.50
7.00
8
948-TPR
131247
D/R170, D/R190
46.000 2.25 I
46 2.35
B
8.50
7.00
8
948-TPR
131428
D/R170, D/R190
37.000 2.06 I
46 2.35
B
8.50
7.00
8
948-TPR
131429
D/R170, D/R190
46.000 2.06 I
46 2.35
B
8.50
7.00
8
948-TPR
131503
D/R170, D/R190
48.835 2.25 I
46 2.35
B
8.50
7.00
8
948-TPR 11.50”
131504
D/R170, D/R190
39.835 2.25 I
46 2.35
B
8.50
7.00
8
948-TPR
131516
S170,S190
45.150 2.25 I
46 2.35
B
8.50
7.00
8
948-TPR
131517
S170,S190
37.716 2.25 I
46 2.35
B
8.50
7.00
8
948-TPR
131717
D/R190D, S190D
46.949 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR 11.50”
131718
D/R190, S190
38.898 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR
131719
D/R190D, S190D
47.500 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR 11.50”
131720
D/R190, S190
38.425 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR
131721
D/R190D, S190D
48.425 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR 11.50”
131722
D/R190, S190
39.331 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR
131723
D/R190, S190
40.394 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR
131724
D/R190D, S190D
50.945 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR 11.50”
131725
D/R190, S190
42.894 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR
131726
D/R190D, S190D
53.445 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR 11.50”
131727
D/R190, S190
45.394 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR
131740
S170D
45.150 2.25 I
46 2.35
B
8.50
7.00
8
948-TPR
131750
D/R190 WT
49.291 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR
131751
D/R190 WT
40.196 2.25 I
46 2.35
B
8.50
7.24
8
948-TPR
131804
D/R170, 190, S170, S190
45.150 2.06 I
46 2.35
B
8.50
7.00
8
773-STR
131805
D/R170, 190, S170, S190
36.150 2.06 I
46 2.35
B
8.50
7.00
8
773-STR
131806
D/R170, 190, S170, S190
45.150 2.25 I
46 2.35
B
8.50
7.00
8
773-STR 11.50”
131807
D/R170, 190, S170, S190
36.150 2.25 I
46 2.35
B
8.50
7.00
8
773-STR
132808
S130
37.834 1.61 I
36 1.85
B
6.22
5.31
8
781-TPR
132809
S130
39.842 1.61 I
36 1.85
B
6.22
5.31
8
781-TPR
132823
S130
39.290 1.61 I
36 1.85
F
6.08
5.22
8
485-STR
132824
S130
41.000 1.61 I
36 1.85
F
6.08
5.22
8
485-STR
132854
S130
38.740 1.61 I
36 1.85
F
6.22
5.31
8
781-TPR
132855
S130
40.433 1.61 I
36 1.85
F
6.22
5.31
8
781-TPR
132856
S110
38.740 1.56 I
34 1.75
F
6.22
5.31
8
781-TPR
132857
S110
40.433 1.56 I
34 1.75
F
6.22
5.31
8
781-TPR
132858
S110
40.287 1.56 I
34 1.75
F
6.08
5.22
8
485-STR
132859
S110
42.000 1.56 I
34 1.75
F
6.08
5.22
8
485-STR
