Axle shafts by part number – Spicer Drive Axles Illustrated Parts List Axle Shafts & Wheel End Parts User Manual
Page 12
10
BODY LENGTH
BOLT HOLE TYPE:
S=Straight
T=Tapered
SPLINE TYPE:
STR=Straight
INV=Involute
A=Angular
BODY O.D.
SPLINE O.D.
NUMBER OF SPLINES
210512
PART NUMBER
FLANGE TYPE:
F=Flathead
B=Bell
BOLT CIRCLE
Axle Shafts by Part Number
Axle Shafts by Part Number
BODY
SPLINE
FLANGE
Bolt
Part
Length Dia. O.D. Flange O.D.
Circle
No.
Hole
Diff Lock
No.
Model
(in)
(in) Type No.
(in)
Type
(in)
(in)
Holes
Type
Spline
056980
17, 34, 340
40.906 1.81 S 16 1.98
F
6.13
5.25
12
781-TPR
062165
17, 34, 340
41.313 1.81 S 16 1.98
F
6.13
5.25
12
781-TPR
065360
13, 15
38.219 1.61 S 19 1.78
B
6.13
5.13
8
781-TPR
076917
38, 380
41.313 1.87 S 16 2.13
B
8.50
7.00
8
635-STR
099407
400, 401, 451
41.219 2.00 I
33 2.13
B
8.50
7.00
8
635-STR
108551
35, 580, 650
41.750 2.25 I
39 2.50
B
8.50
7.00
8
948-TPR
108552
35, 580, 650
43.750 2.25 I
39 2.50
B
8.50
7.00
8
948-TPR
108555
35, 580, 650
44.250 2.25 I
39 2.50
B
8.50
7.00
8
948-TPR
108556
35, 580, 650
45.250 2.25 I
39 2.50
B
8.50
7.00
8
948-TPR
110880
13, 15
38.219 1.61 I
34 1.75
B
6.22
5.13
8
720-TPR
110882
17, 34, D/R340, 341
40.906 1.81 I
39 2.00
F
6.13
5.25
12
781-TPR
110886
17, 34, D/R340, 341
41.313 1.81 I
39 2.00
F
6.13
5.25
12
748-TPR
110888
38, 380, 381, 402
41.313 1.87 I
41 2.11
B
8.50
7.00
8
635-STR
110889
19, 23, 26, 44, 440, 460, 480, 461, 462
40.875 2.06 I
36 2.31
B
8.50
7.00
8
635-STR
110890
19, 23, 26, 44, 440, 460, 480, 461, 462
41.063 2.06 I
36 2.31
B
8.50
7.00
8
948-TPR
111544
15
38.843 1.61 I
34 1.75
B
6.22
5.31
8
781-TPR
111545
16220
38.678 1.69 I
36 1.85
B
6.24
5.31
8
781-TPR
113334
D/R401, 451
40.750 2.06 I
33 2.13
B
5.20
7.00
8
733-STR
113335
440, 461
40.000 2.06 I
36 2.31
B
8.50
7.00
8
773-STR
113503
D/R404, Wide Track
46.156 1.87 I
41 2.11
B
8.50
7.00
8
948-TPR
113645
16
40.563 1.69 I
36 1.85
F
6.13
5.25
12
781-TPR
118866
13, 15
38.219 1.61 I
34 1.75
B
6.22
5.31
8
781-TPR
119409
580, 650
42.750 2.25 I
36 2.31
B
8.50
7.00
8
948-TPR
119592
15
38.500 1.61 I
34 1.75
F
6.19
5.22
8
566-STR
119593
16
39.500 1.69 I
36 1.85
F
6.19
5.22
8
566-STR
119594
17, 341
40.906 1.81 I
39 2.00
F
6.63
5.50
8
640-STR
119596
23
40.750 2.06 I
36 2.31
B
8.50
7.00
8
773-STR
119639
D/R480
40.313 2.25 I
36 2.31
B
8.50
7.00
8
948-TPR
119904
D/R521, 581, 601, 651
45.250 2.25 I
36 2.31
B
8.50
7.00
8
948-TPR
119905
521
47.750 2.25 I
36 2.31
B
8.50
7.00
8
948-TPR
126160
D/R401, 451
41.375 2.06 I
33 2.13
B
8.50
7.00
8
948-TPR
