Flange Yokes
Bearing Plate Design
9
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued Part is available until supply is exhausted
©
Not sold separately
A
B - Bolt Holes
C
G
Flange or
Bolt
Diameter
Number Pilot Diameter
Flange
Illustration Spicer
Swing
Circle
D-Drilled
of
M-Male
Face to
Figure
Part
Diameter
Diameter
T-Tapped
Holes
F-Female
Centerline
Number
Figure 1
Figure 4
Figure 3
Figure 6
Figure 2
Figure 5
Side View of
Figures 1, 2, 4 & 6
Side View of
Figures 3 & 5
1610 SERIES
E-5.312 D-1.875 USE KIT N0. 5-279X, 5-674X
6.875
6.125
.375-D
8
5.312M
2.750
2
5-2-599
Flange has pilot for brake
6.875
6.125
.375-D
8
5.312M
1.875
2
5-2-989
Flange has pilot for brake
6.875
6.125
.375-D
8
5.312M
2.750
5
5-2-599-1
B.S./H.R.style w/brake pilot.
6.875
6.125
.375-D
8
5.375F
1.875
2
5-2-1089
Part has opening cast thru web
6.875
6.125
.375-D
8
5.375F
2.750
2
5-2-249
6.875
6.125
.375-D
8
6.625M
2.750
2
5-2-279
6.875
6.125
.375-D
8
6.625M
1.875
2
5-2-379
6.875
6.125
.440-D
12
6.625M
2.750
6
5-2-1159•
8.000
7.250
.375-D
8
6.435M
2.750
5
5-2-1249-1
B.S./H.R.style w/brake pilot.
8.000
7.250
.375-D
8
6.435M
2.750
3
5-2-709-1•
B.S./H.R.style w/brake pilot.
8.000
7.250
.375-D
8
6.435M
2.750
2
5-2-709
Flange has pilot for brake
8.000
7.250
.375-D
8
7.750M
2.750
2
5-2-629
8.000
7.250
.375-D
8
7.750M
1.875
2
5-2-619
Part has opening cast thru web
1710 SERIES
E-6.094 (HR STYLE-6.190) D-1.938 USE KIT NO. 5-280X, 5-675X
7.087
5.906
.590-D
4
.000
3.268
4
6-2-25
180 mm flange w/serrated flange face
8.000
5.118
.472-D
4
.000
3.189
4
6-2-15
150 mm flange w/serrated flange face
8.000
7.250
.375-D
8
6.438M
3.000
5
6-2-1439-1
B.S./H.R.style w/brake pilot.
8.000
7.250
.375-D
8
6.438M
3.000
2
6-2-789
Flange has pilot for brake
8.000
7.250
.375-D
8
7.750M
2.000
2
6-2-769
8.000
7.250
.375-D
8
7.750M
3.000
5
6-2-749-1
Part has opening cast thru web
Continued on next page
