Flange yokes, Snap ring design, J300p-2 – Spicer DRIVELINE COMPONENTS CATALOG FLANGE YOKES User Manual
Page 6
J300P-2
Flange Yokes
Snap Ring Design
Figure 1
Figure 2
Figure 3
Important: See Safety Information in General Information Section (J300P-GI)
6
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued Part is available until supply is exhausted
©
Not sold separately
A
B - Bolt Holes
C
G
Flange or
Bolt
Diameter
Number Pilot Diameter
Flange
Illustration Spicer
Swing
Circle
D-Drilled
of
M-Male
Face to
Figure
Part
Diameter
Diameter
T-Tapped
Holes
F-Female
Centerline
Number
Important: See Safety Information in General Information Section (J300P-GI)
1310 SERIES (Continued) E-3.469 D-1.062 USE KIT NO. 5-153X, 5-785X, 5-810X, 5-1200X
4.500
3.500
.500-D
4
2.000F
1.650
1
2-2-939
Bolt holes are equally spaced. Part has hole thru center.
4.580
3.750
.440-D
4
2.750M
1.190
1
2-2-1039•
4.678
3.740
.469-D
4
2.558M
1.781
1
2-2-1729
4.625
3.750
.406-D
4
2.559M
1.772
1
2-2-1799
10 mm bolt holes, equally spaced
4.625
3.750
.438-D
4
2.750M
1.375
1
2-2-479
4.719
3.750
.481-D
4
2.558M
1.781
1
2-2-1949
12 mm bolt holes equally spaced.
4.740
3.740
.478-D
4
1.964M
1.780
1
2-2-2029
Bolts holes are equally spaced
4.750
3.750
.503-D
4
2.750M
2.000
1
2-2-1789
10 mm bolt holes, equally spaced
4.906
3.937
.489-D
4
2.162F
1.930
1
2-2-1989
Bolt holes are equally spaced. Part has hole thru center.
5.219
4.250
.484-D
4
2.000F
1.625
1
2-2-1379
Bolt holes are equally spaced. Part has hole thru center.
5.750
4.750
.507-D
4
3.750M
1.375
1
2-2-579
1330 SERIES
E-3.875 D-1.062 USE KIT NO. 5-213X, 5-790X, 5-812X, 5-1203X
3.880
3.000
.487-D
4
2.436F
1.618
1
2-2-01474
4.469
3.500
.484-D
4
2.000F
1.625
1
2-2-949
Bolts holes are equally spaced
4.528
3.661
.446-D
4
1.811M
1.653
1
5001904
5001904 was replaced by 2-2-01904
4.528
3.661
.446-D
4
1.811M
1.653
1
2-2-01904
4.625
3.750
.438-D
4
2.750M
1.562
1
2-2-1209
4.625
3.750
.438-D
4
2.750M
1.562
1
2-2-489
4.960
3.938
.489-D
4
2.161F
1.930
1
2-2-1879•
5.118
3.674
.482-D
4
1.811M
1.653
1
2-2-02768
Bolts holes are equally spaced
5.156
4.250
.453-D
4
3.125F
1.688
1
2-2-1399
Bolts holes are equally spaced
Continued on next page
