How to use this catalog – Spicer DRIVELINE COMPONENTS CATALOG FLANGE YOKES User Manual
Page 2
Important: See Safety Information in General Information Section (J300P-GI)
2
Important: See Safety Information in General Information Section (J300P-GI)
J300P-2
HOW TO USE THIS CATALOG
Important: See Safety Information in General Information Section (J300P-GI)
2).
The Series of the Part
SPL
•
®
flange yokes that are spring tab or strap design can be found on pages 3 through 4.
Flange yokes that are snap ring
•
or strap design can be found on pages 5 through 8.
Flange yokes that are bearing plate design can be found on pages 9 through 11.
•
A part number index is provided on page 12.
•
Footnotes for parts and assemblies that are discontinued, will be discontinued or replaced upon
depletion of stock, or not sold separately, are indicated by a symbol next to the part number. Match
the symbol to the appropriate status at the bottom of the page. All other footnotes are located
immediately below the yoke dimensional data.
To identify a Flange Yoke, two pieces of information are needed:
1).
The Design of the Part
SNAP RING
BEARING PLATE
BEARING STRAP
