21
Differential Case Oil Scoop Bolts W 1/4" - 20 8 7 - 9 9 - 12
Differential Case Bolts J 9/16" - 18 8 115 - 135 156 - 183
Carrier Mounting Bolts All 5/8" - 11 8 160 - 185 217 - 250
W 5/8" - 18 8 160 - 185 217 - 250
Differential Bearing Cap Bolts All 3/4" - 10 8 275 - 320 370 - 435
Pinion Bearing Cage Bolts J 9/16" - 12 8 115 - 135 155 - 183
AXLE/TORQUE SPECIFICATIONS
Flanged Hex Nut All 1-3/4" - 12 8 900 - 1,200 1,220 - 1,627
P PP P Position osition osition osition osition Gr Gr Gr Gr Grade ade ade ade ade Lb-Ft Lb-Ft Lb-Ft Lb-Ft Lb-Ft N-m N-m N-m N-m N-m Thr Thr Thr Thr Thread ead ead ead ead Model Model Model Model Model
W 5/8" - 11 8 160 - 185 217 - 250
Hex Head Fasteners
Pinion Nominal Dimension J 3.7695" 95.745 mm
W 4.2845" 108.826 mm
Lube Capacity (Approx.**) J 31.5 pints 15.0 liters
Lubrication
W 50 tons 45 tonnes
W .012" - .016" .30 - .40 mm
Differential
Pull Scale J, W 3 - 9 Lb-Ft 1.4 - 4.0 Kg
Pinion Bearing Preload*
It It It It Item em em em em Model Model Model Model Model
Axle Specifications
Me Me Me Me Metric tric tric tric tric U.S. U.S. U.S. U.S. U.S.
Torque Wrench J, W 10 - 30 Lb-in 1.1 - 3.4 N-m
Ring Gear to Pinion Backlash J .006" - .012" .23 - .33 mm
Ring Gear Rivet Pressure J 45 - 50 tons 41 - 45 tonnes
Lube Capacity (Approx.**) W 34.5 pints 16.5 liters
*
Pinion bearing preload is established prior to installation of pinion seal.
** Capacity will vary depending on the housing angle in each vehicle. Fill to lower edge of fill hole in rear of axle housing as shown on page 4.
J190-S thru W230-S 3/4" - 16 5 Nylok 217 - 240 290 - 325
Axle Flange to Wheel Hub Nuts J175-S Only 5/8" - 18 5 Nylok 125 - 145 170 - 195
Fill & Magnetic Drain Plugs All 3/4" - 14 8 35 - 45 47 - 61
Differential Case Bolts J 9/16" - 18 8 115 - 135 156 - 183
Carrier Mounting Bolts All 5/8" - 11 8 240 - 260 330 - 358
W 5/8" - 18 8 160 - 185 217 - 250
Differential Bearing Cap Bolts All 3/4" - 10 8 390 - 410 536 - 563
Flanged Hex Nut All 1-3/4" - 12 8 900 - 1,200 1,220 - 1,627
P PP P Position osition osition osition osition Gr Gr Gr Gr Grade ade ade ade ade Lb-Ft Lb-Ft Lb-Ft Lb-Ft Lb-Ft N-m N-m N-m N-m N-m Thr Thr Thr Thr Thread ead ead ead ead Model Model Model Model Model
W 5/8" - 11 8 240 - 260 330 - 358
Flange Head Fasteners
Pinion Bearing Cage Bolts J 9/16" - 12 8 160 - 180 217 - 248
Axle Flange to Wheel Hub Nuts J175-S Only 5/8" - 18 8 Steel 160 - 185 217 - 250
J190-S thru W230-S 3/4" - 16 8 Steel 275 - 320 370 - 435
