YOKE SHAFTS
J300P-8
9
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued Part is available until supply is exhausted
©
Not sold separately
K
Centerline to
End of Spline
R
End of Spline to
Point of Radius
L
Spline
Length
Yoke Shaft
Part Number
Notes
1810 SERIES
E=7.547 (HR STYLE=7.643) D=1.938
USE KIT NO. 5-281X, 5-676X
3.000-16 Spline
10.438
6.562
4.000
6.5-82-451-12 High angle yoke
11.438
7.812
4.000
6.5-82-451-1
High angle yoke
11.938
8.312
4.000
6.5-82-451-3
High angle yoke
12.188
8.562
4.500
6.5-82-461-1
High angle yoke
12.438
8.813
4.000
6.5-82-451-5
High angle yoke
12.688
9.062
4.500
6.5-82-461-2
High angle yoke
13.188
9.562
4.500
6.5-82-461-3
High angle yoke
13.688
10.062
4.500
6.5-82-461-4•
High angle yoke
13.812
10.188
4.500
6.5-82-461-8
High angle yoke
14.438
10.812
4.500
6.5-82-461-9
High angle yoke
15.062
11.438
4.500
6.5-82-461-10 High angle yoke
15.688
12.062
4.500
6.5-82-461-11 High angle yoke
16.312
12.688
4.500
6.5-82-461-12 High angle yoke
3.248-18 Involute Spline
6.719
4.312
2.750
6.5-82-511-1
7.219
4.812
2.750
6.5-82-511-3
1880 SERIES
E=8.094 D=2.188
USE KIT NO. 5-308X
3.000-16 Spline
12.844
8.531
4.500
8-82-161-1
14.844
10.531
4.500
8-82-161-6
17.469
13.156
4.500
8-82-161-12
4.156-24 Involute Spline
7.219
4.156
2.625
8-82-171-1
