YOKE SHAFTS
J300P-8
8
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued Part is available until supply is exhausted
©
Not sold separately
K
Centerline to
End of Spline
R
End of Spline to
Point of Radius
L
Spline
Length
Yoke Shaft
Part Number
Notes
1710 SERIES (Continued) E=6.094 (HR STYLE=6.190) D=1.938 USE KIT NO. 5-280X, 5-675X
2.500-16 Spline (Continued)
14.000
9.875
4.000
6-82-1341-4
High angle yoke
14.156
10.469
4.000
6-82-1091-3
High angle yoke
14.281
10.156
4.000
6-82-1341-5
High angle yoke
14.750
10.625
4.000
6-82-1341-6
High angle yoke
15.031
10.906
4.000
6-82-1341-7
High angle yoke
15.375
11.250
4.000
6-82-1341-8
High angle yoke
15.750
11.625
4.000
6-82-1341-9
High angle yoke
16.031
11.906
4.000
6-82-1341-10
High angle yoke
16.406
12.281
4.000
6-82-1341-11
High angle yoke
16.688
9.562
4.000
6-60-275-0214• High angle yoke
16.750
12.625
4.000
6-82-1341-12
High angle yoke
16.875
9.562
4.000
6-60-275-0220• High angle yoke
17.031
13.281
4.000
6-60-275-0225• High angle yoke
17.500
13.750
4.000
6-60-275-0308• High angle yoke
3.248-18 Involute Spline
5.050
2.890
1.810
6-82-01146
5.250
3.016
2.000
6-82-341
6.125
3.875
2.000
6-82-691
7.250
4.938
2.000
6-82-411
7.875
5.563
2.000
6-82-1001
1760 SERIES
E=7.000 (HR STYLE=7.094) D=1.938
USE KIT NO. 5-407X, 5-677X
2.500-16 Spline
11.000
8.188
4.000
6.3-82-21-1
11.500
8.688
4.000
6.3-82-21-2•
12.000
9.188
4.000
6.3-82-21-3
12.375
9.562
4.000
6.3-82-21-5•
12.500
9.688
4.000
6.3-82-21-4§
12.875
10.062
4.000
6.3-82-21-6•
13.375
10.562
4.000
6.3-82-21-7•
13.875
11.062
4.000
6.3-82-21-8•
14.375
11.562
4.000
6.3-82-21-9•
14.875
12.062
4.000
6.3-82-21-10•
15.375
12.562
4.000
6.3-82-21-11
