YOKE SHAFTS
J300P-8
7
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued Part is available until supply is exhausted
©
Not sold separately
K
Centerline to
End of Spline
R
End of Spline to
Point of Radius
L
Spline
Length
Yoke Shaft
Part Number
Notes
1610 SERIES (Continued) E=5.312 (HR STYLE E=5.312) D= 1.875 USE KIT 5-279X, 5-674X
2.672-17 Based On 18 Spline
4.219
2.531
1.594
5-82-191•
2.672-18 Involute Spline
6.063
4.003
1.500
5-82-951
Spline not glidecoated
6.850
4.790
1.500
5-82-951-2
Spline not glidecoated
7.140
5.080
1.500
5-82-951-1
Spline not glidecoated
2.674-18 Involute Spline
4.125
2.500
1.500
5-82-161
1710 SERIES
E=6.094 (HR STYLE=6.190) D=1.938
USE KIT NO. 5-280X, 5-675X
2.500-15 Based On 16 Spline
9.656
6.656
3.500
6-82-1331-1
2.500-16 Spline
8.156
5.406
3.000
6-82-1251
8.531
5.781
3.500
6-82-1131-2
8.650
5.906
3.000
6-82-1391
8.910
5.570
2.750
6-82-1371
9.031
6.281
3.375
6-82-1291
9.063
6.312
3.500
6-82-1131-4•
9.656
6.312
3.500
6-82-1171-10
9.820
6.480
3.160
6-82-1411
10.031
6.688
3.500
6-82-1171-1
10.156
6.812
3.500
6-82-1171-11
10.320
6.980
3.160
6-82-1381
10.656
7.312
3.500
6-82-1171-12
10.656
6.906
3.500
6-82-1281-6
High angle yoke
10.660
6.540
3.500
6-82-1351-5
High angle yoke
11.000
8.000
4.000
6-82-1231
11.031
7.688
3.500
6-82-1171-7§
11.156
7.812
3.500
6-82-1171-2
11.531
8.094
4.000
6-82-1141
11.656
8.312
3.500
6-82-1171-13
11.660
8.656
3.500
6-82-1351-7
High angle yoke
11.781
8.094
4.000
6-82-1091-12
12.000
8.312
4.000
6-82-1091-16•
12.094
8.344
3.500
6-82-1281•
High angle yoke
12.094
7.969
3.500
6-82-1351-2
High angle yoke
12.156
8.469
4.000
6-82-1091-1
12.281
8.594
4.000
6-82-1091-13
12.438
9.094
3.500
6-82-1171-6
12.594
8.844
3.500
6-82-1281-3
High angle yoke
12.688
8.562
4.000
6-82-1341-1
High angle yoke
12.781
8.656
3.500
6-82-1351-3
High angle yoke
13.000
9.656
3.500
6-82-1171-5•
13.094
9.344
3.500
6-82-1281-1
High angle yoke
13.094
8.969
3.500
6-82-1351-4
High angle yoke
13.156
9.460
4.000
6-82-1341-13
High angle yoke
13.375
9.625
4.000
6-82-1061-15
High angle yoke
13.375
9.250
4.000
6-82-1341-2
High angle yoke
13.625
9.938
4.000
6-82-1091-9
High angle yoke
13.750
9.625
4.000
6-82-1341-3
High angle yoke
