Page 5
YOKE SHAFTS
J300P-8
5
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued Part is available until supply is exhausted
©
Not sold separately
K
Centerline to
End of Spline
R
End of Spline to
Point of Radius
L
Spline
Length
Yoke Shaft
Part Number
Notes
1350 SERIES
E=3.875 (UB,BS STYLE E=3.625) D=1.188
USE KIT 5-178X, 5-1350X
1.175-27 Spline
6.062
2.031
1.844
3-82-1201•
Wheel yoke shaft, BS Style
1.175-27 Involute Spline
5.531
3.062
1.750
3-82-1161
Wheel yoke shaft, BS Style
1.177-27 Involute Spline
6.740
3.481
1.844
3-82-1141-1•
GM differential yoke shaft, BS style
7.290
4.031
1.844
3-82-1141-2•
GM differential yoke shaft, BS style
1.252-31 Involute Spline
4.547
1.719
1.440
3-82-1381•
GM differential yoke shaft, BS style
4.547
1.719
1.440
3-82-1431•
1.302-30 Involute Spline
6.590
5.430
2.219
3-82-1151-2
Wheel yoke shaft, BS Style
7.360
5.750
2.219
3-82-1151-1•
Wheel yoke shaft, BS Style
7.422
4.340
2.000
3-82-961-2•
BS style
1.500-10 Spline
5.820
—
1.500
3-82-981
Has .375"-16 threaded hole at spline end
1.500-16 Spline
4.188
2.531
1.375
3-82-971
4.812
2.781
1.750
3-82-71
Spline not glidecoated
5.188
3.063
2.000
3-82-61
Spline not glidecoated
5.844
3.781
2.000
3-82-1321
6.406
4.344
2.000
3-82-341
Spline not glidecoated
6.531
4.406
2.500
3-82-161
Spline not glidecoated
6.812
4.688
2.500
3-82-181
Spline not glidecoated
7.250
5.125
2.500
3-82-211
Spline not glidecoated
7.750
5.125
2.500
3-82-761X
Spline not glidecoated
1410 SERIES
E=4.438 (UB,BS STYLE E=4.188) D=1.188
USE KIT 5-160X, 5-1410X
1.358-21 Involute Spline
5.547
2.700
2.000
3-82-1291•
1.500-16 Spline
4.969
3.250
2.000
3-82-1191
5.406
3.312
2.000
3-82-1301§
6.312
4.470
2.500
3-82-201
Spline not glidecoated
7.844
5.250
3.000
3-82-168X•
Spline not glidecoated
8.406
5.750
3.000
3-82-58X
Spline not glidecoated
8.969
6.281
3.000
3-82-268X
Spline not glidecoated
1.750-16 Spline
4.547
2.672
1.438
3-82-261
5.406
3.531
1.438
3-82-811
6.340
4.410
3.000
3-82-781
Spline not glidecoated
1480 SERIES
E=4.438 (UB,BS STYLE E=4.188) D=1.375
USE KIT 5-188X,SPL55X
1.562-16 Spline
6.750
4.500
2.750
3-82-1121
2.250-10 Spline
4.380
2.812
1.594
3-82-271
2.994-24 Involute Spline
8.960
6.149
4.566
5005288©
5005288 was replaced by 5007951;
Sold only in assy# 5007951; Material: aluminum
