Spicer Driveline Components Catalog - Yoke Shafts - Manual (Page 2)

2 Important: See Safety Information in General Information Section (J300P-GI)
K
Centerline to
End of Spline
R
End of Spline to
Point of Radius
L
Spline
Length
Yoke Shaft
Part Number
Notes
1550 SERIES E-5.250 D-1.375 USE KIT NO. 5-155X, 5-808X
1.750-16 Spline
4.750 2.500 1.438 4-82-341•
6.375 4.156 2.500 4-82-601-1• High angle yoke
6.375 4.156 2.500 4-82-601-2• High angle yoke
6.812 4.250 2.500 4-82-371 High angle yoke
7.940 5.375 3.000 4-82-411-7 High angle yoke
HOW TO USE THIS CATALOG
To identify a yoke shaft:
1. Determine the Series
2. Determine the spline outside diameter and number of teeth.
3. Determine the length from centerline of joint to end of spline.
Use of the above data will narrow the selection down to a specific yoke shaft with exact dimensions
or a selection of yoke shafts having common dimensions.
Within those common shafts, there may be part numbers that have different lengths of spline,
different distances from the end of the spline to the radius at the neck of the shaft or different
maximum working angles.
Footnotes for parts and assemblies that are discontinued, will be discontinued upon depletion of
stock, or not sold separately, are indicated by a symbol next to the part number. Match the symbol
to the appropriate status at the bottom of the page. All other footnotes are located immediately
below the yoke dimensional data.
Series and all pertinent series dimensions appear as shown in the samples below:
Spicer Life Series ® :
All Others:
IMPORTANT NOTICE: The data listed herein is correct to the best of our knowledge and
belief; having been compiled from reliable and official sources of information. However, WE
CANNOT ASSUME ANY RESPONSIBILITY for possible error.
2
3
1
1
2
3
SPL140 SERIES E-5.028 D-1.936 USE KIT SPL140X
3.071-30 Involute Spline
11.811 8.661 1 91-30-2-132M 140-68-13 140-82-21X
SPL170 SERIES E-6.024 D-2.166 USE KIT SPL170X
3.464-34 Involute Spline
11.062 7.500 1 100-30-2-84M 6-68-64 170-82-191X
K
Centerline
to End of
Spline
Boot Can/
Tube Assembly
Part Number
Plug Part
Number
Yoke Shaft
Part Number
L
Centerline
to End of
Can/Tube
Style
