48
Input and Output Yokes
Forward Axles Rear Axles
Input (Yoke & Slinger) (46 involute splines) Pinion (Yoke & Slinger) (41 involute splines)
Yoke Joint Part Yoke Joint Part
Series Angle Style No. Series Angle Style No.
82N — X 126318 72N — X 126319
1710 30.0
°
Y 126581 1550 18.0
°
Z 126537
1710 22.5
°
Z 126686 1610 24.0
°
Z 126547
1760 30.0
°
Y 126583 1610 26.0
°
Y 126539
1760 30.0
°
Z 126688 1610 45.0
°
Y 126587
1810 30.0
°
Z 126690 1710 29.0
°
Z 126549
1810 30.0
°
Y 126585 1710 30.0
°
Y 126541
1710 39.0
°
Z 127702
1710 42.5
°
Y 126589
1760 29.0
°
Y 126543
1760 30.0
°
Z 126551
1810 30.0
°
Y 126545
1810 30.0
°
Z 126553
Output (Yoke & Slinger) (41 involute splines)
Yoke Joint Part
Series Angle Style No.
72N ——– X 126317
1610 45.0
°
Y 126650
1710 38.0
°
Y 126651
1760 38.0
°
Y 126652
1810 30.0
°
Y 126653
Yoke Styles:
X — Thru Holes / Half Round (U-Bolt)
Y — Full Round
Z — Tapped Holes / Half Round (Brg. Strap)
See information for New Oil Seals for Input and Output Yoke Assemblies before ordering
STYLE X STYLE Y STYLE Z
Thru Holes / Half Round
(U-Bolt)
Full Round Tapped Holes/ Half Round
(Bearing Strap)
CUT 61904-4/93
Appendix
