21
Item Description Qty Order Part No. Notes
1 Diff. Carrier & Bearing Caps 1 98590 Includes Items 2-5, 9, 11-12, 14-15,
Carrier Casting No 127218R NSS 17-18, 25 & RTV
2 Bearing Cap Screw 2 32732
2 127180
3 Flat Washer 4 32912
4 Lockwire 4 12563
5 Dowel Bushing 2 32730
6 Bearing Cap Adjuster Lock (RH) 1 14275
7 Cotter Pin (RH) 1 90876
8 Bearing Cap Adjuster Lock (LH) 1 78926
9 Dowel Bushing 2 37746 For Bearing Adjuster Locks
10 Adjuster Lock Cap Screw 2 210601
11 Expansion Plug (Upper) 1 30703*
Expansion Plug (Lower) 1 9797*
12 Shift Fork Shaft & "O" Ring Assy 1 113801 RT only
(Shaft 41103 NSS; "O" Ring 113140)
13 Shift Fork & Roller Assy 1 84508 RT only
14 Shift Fork Mounting Stud 2 119863 RT only
15 Shift Fork Seal & Spring Assy 1 119855* RT only
16 Shift Unit Assy 1 73507 RT only
17 Flat Washer 2 119857 RT only
18 Stud Nut 2 63028 RT only
19 Diff. Bearing Adjuster (RH) 1 21637
Diff. Bearing Adjuster (LH) 1 126305
20 Diff. Bearing Cup (RH) 1 15092*
Diff. Bearing Cup (LH) 1 21632*
21 Diff. Bearing Cone (RH) 1 27876*
Diff. Bearing Cone (LH) 1 102660*
22 Sliding Clutch 1 126255 RT only
23 Sun Gear 1 119902 RP only
24 Sun Gear Retainer 1 43178 RP only
25 Shift Unit Opening Cover 1 45521 RP only
26 Cap Screw 2 20807 RP only
27 Lockwasher 2 90415 RP only
28 Gear Support Case (RH) 1 108138
Gear Support Case (LH) 1 126301
RT/RP461
RT/RP521
RT/RP601
RT/RP651
Rear Axle
Dual Range & Planetary
Double Reduction
