9
DS461-P
DS521-P
DS581-P
Single Reduction
Forward Axle
Item Description Qty Order Part No. Notes
33 Pinion Bearing Cage Shim AR
.003" 45461*
.005" 62829*
.010" 45462*
.020" 62830*
34 Bearing Cage Cap Screw 6 62158
35 Lockwasher 6 37207
36 Pinion Helical Gear 1 119995
37 Outer Pinion Bearing & Race 1 78916*
38 Outer Pinion Bearing Snap Ring 1 78937*
39 Pinion Shaft End Nut 1 126182
40 Pinion Nut Spring Pin 1 118807
41 Output Shaft Nut 1 210508
42 Output Shaft Washer 1 210509
43 Output Shaft Yoke 1 See Appendix:Input/Output Yoke Information
44 Rear Bearing Retaining Washer 1 78922*
45 Axle Housing Cover Assy 1 107863 Includes Items 46-49
(Cover 84546) NSS
46 Output Shaft Oil Seal 1 119429* or 210737* See Appendix:Input/Output Yoke Information
47 Bearing Snap Ring 1 78937*
48 Output Shaft Bearing Race – Inner 1 118787* Order #78936 Brg Assy
48 Output Shaft Bearing Race – Outer 1 118788* Order #78936 Brg Assy
49 Magnetic Filler Plug 1 75130 7 /
8
"
49 Retainer Plug 1 90898 1 /
2
"
50 Output Shaft Kit 1 122419 Includes Items 41,42, 51,52,56
(Shaft 119991, 41 Splines 2.100" dia) NSS
51 Output Shaft Bushing 1 48922*
52 Output Shaft "O" ring 2 78931*
53 Output Shaft Bearing Cup (Inner) 1 24328*
54 Output Shaft Bearing Cone (Inner) 1 24330*
55 Output Shaft Side Gear 1 78911
56 Side Gear Snap Ring 1 85994*
57 Output Shaft Compression Spring 1 127095
58 Output Shaft Thrust Bearing 1 51228
59 Inter-axle Diff. Assy 1 121681 Includes Items 60-65
60 Inter-axle Diff Case Kit 1 211252 Includes Items 60-62
60 Case Half NSS 2 126151 Order 211252
61 Case Bolt 8 57636
Note: Item 46 Output Shaft Oil Seal — See Appendix:Input/Output Yoke Information before ordering.
