Spicer Tandem Drive Axle: DS_RS461, 462, 463, 521, 581, DT_RT_DP_RP461, 462, 463, 521, 581, 601, 651 User Manual
Page 3
1
Introduction
Contents
Introduction
Models Listing -------------------------------------------------------------------------------
2
How to Use The Illustrated Parts List ----------------------------------------------------
3
Model Identification ------------------------------------------------------------------------
4-5
Single Reduction
DS461-P • DS521-P • DS581-P ----------------------------------------------------------
6-11
RS461 • RS521 • RS581 ------------------------------------------------------------------
12-13
Dual Range & Planetary Double Reduction
DT/DP461-P • DT/DP521-P • DT/DP601-P• DT/DP651-P -----------------------------
14-19
RT/RP461 • RT/RP521 • RT/RP601 • RT/RP651 ---------------------------------------
20-23
Planetary Double Reduction
TP/SP461 • TP/SP521• TP/SP601 • TP/SP651 -----------------------------------------
24-29
Shift System
Differential Lockout Assembly - Current Production -----------------------------------
30
Air Operated Lockout Assembly - Non-Current Production ---------------------------
31
Axle Range Selection & Differential Lockout System ----------------------------------
32 -33
Axle Shift System --------------------------------------------------------------------------
34
Air Shifter Valve -----------------------------------------------------------------------------
35
Piston Air Shift System --------------------------------------------------------------------
36-37
Axle Housings & Shafts
461,521,581,601 Forward/Rear Housings ----------------------------------------------
38
651 Housings --------------------------------------------------------------------------------
38
Axle Shaft Configurations -----------------------------------------------------------------
39
Axle Hsg/Shafts Models: D521/D581/D601/T521/T601/S521/S601 ------------------
40
Axle Hsg/Shafts Models: D651/T651/S651 ----------------------------------------------
41
Appendix
Gear and Pinion Information
* ------------------------------------------------------------
42-43
* Pinion Bearing Spacer information included
Differential Carrier Assemblies------------------------------------------------------------
44-45
Input/Output Yoke Information -----------------------------------------------------------
46-48
