Spicer Tandem Drive Axle: DS_RS461, 462, 463, 521, 581, DT_RT_DP_RP461, 462, 463, 521, 581, 601, 651 - Manual (Page 19)

17
Item Description Qty Order Part No. Notes
34 Thrust Washer (RH) 1 43271* For High-Speed CL Plate
35 Idler Pinion Pin 4 126302
36 Idler Pinion 4 126306
37 High-Speed Clutch Plate 1 126307
38 Diff. Case w/clutch plate pin 1 126304 NSS Casting #108139 - order 122417
Diff. Case (RH) 1 108140 NSS - order 122417
39 Diff. Case Cap Screw 4 96285 Short
Diff. Case Cap Screw 8 96284 Long
40 Diff. Side Gear 2 118959 36 Involute
41 Side Gear Thrust Washer 2 83726*
Gear Support Thrust Washer 1 83726*
42 Side Pinion 4 108142
43 Side Pinion Thrust Washer 4 108145*
44 Spider 1 108141
45 Pinion Pilot Bearing 1 126187*
46 Pinion Bearing Cone 2 14218*
47 Pinion Bearing Spacer Washer 1 78904*
48 Pinion Bearing Spacer * AR See Appendix: Gear & Pinion Information
49 Pinion Bearing Cup 2 14217*
50 Pinion Bearing Cage & Cup Assy 1 78914 Cage (78932) Includes Item 49
51 Pinion Bearing Cage Shim AR
.003" 45461*
.005" 62829*
.010" 45462*
.020" 62830*
.030" 45463*
52 Bearing Cage Cap Screw 6 62158
53 Lockwasher 6 37207
54 Pinion Helical Gear 1 119995
55 Outer Pinion Support Brg & Race 1 78916*
56 Outer Pinion Bearing Snap Ring 1 78937*
57 Pinion Shaft End Nut 1 126182
58 Pinion Nut Spring Pin 1 118807
59 Output Shaft Nut 1 210508
60 Output Shaft Washer 1 210509
61 Washer - Brg Spacer 1 78922
62 Axle Housing Cover Assy
(Cover 84546) NSS 1 107863 D461, D521, D601
Includes Items 63-66
(Cover 78923) NSS 1 108099 D651, T651
DT/DP461-P
DT/DP521-P
DT/DP601-P
DT/DP651-P
Forward Axle
Dual Range & Planetary
Double Reduction
* Note: Pinion Bearing Spacer information is included in the Appendix: Gear & Pinion Information
