27
Item Description Qty Order Part No. Notes
32 Side Gear Thrust Washer 2 83726
Gear Support Thrust Washer 1 83726
33 Side Pinion 4 108142
34 Side Pinion Thrust Washer 4 108145
35 Spider 1 108141
36 Pinion Pilot Bearing 1 126187
37 Pinion Bearing Cone 2 14218
38 Pinion Bearing Spacer Washer 1 78904
39 Pinion Bearing Spacer * AR See Appendix: Gear & Pinion Information
40 Pinion Bearing Cup 2 14217
41 Pinion Bearing Cage & Cup Assy 1 78914 Cage (78932) Includes Item 40
42 Pinion Bearing Cage Shim AR
.003" 45461
.005" 62829
.010" 45462
.020" 62830
.030" 45463
43 Bearing Cage Cap Screw 6 62158
44 Lockwasher 6 37207
45 Pinion Helical Gear 1 119997 1:1 Ratio
Must be used with Helical Side
Gear of same ratio 1 119998 1.2:1 Ratio Old #98392
46 Outer Pinion Support Bearing & Race 1 78916
47 Outer Pinion Bearing Snap Ring 1 78937
48 Pinion Shaft End Nut 1 126182
49 Pinion Nut Spring Pin 1 118807
50 Output Shaft Nut 1 210508 TP only
51 Output Shaft Washer 1 210509 TP only
52 Output Yoke 1 See Appendix:Input/Output Yoke Information
53 Axle Housing Cover Assy - Not Sold Separately (NSS):
Cover 78923 (NSS) 1 108099 TP651 Includes Items 54, 56-58
Cover 84546 (NSS) 1 107863 TP521, TP601 Includes Items 54, 56-58
Cover 80269 (NSS) 1 98276 SP521, SP601, SP651
54 Output Shaft Oil Seal 1 119429or 210737* See Appendix:Input/Output Yoke Information
TP only
55 Rear Bearing Retaining Washer 1 78922 TP only
56 Bearing Snap Ring 1 78937 TP only
57 Output Shaft Bearing Race - Inner 118787 TP only, Order 78936 Brg Assy
57 Output Shaft Bearing Race - Outer 1 118788 TP only, Order 78936 Brg Assy
58 Magnetic Filler Plug 1 75130 7 /
8
"
Retainer Plug 1 90898 1 /
2
"
59 Input Shaft Bearing Cup (Inner) 1 98388
Input Shaft Bearing Cup (Outer) 1 98385 Included with Item No. 66
60 Input Shaft Bearing Cone (Inner) 1 98387
Input Shaft Bearing Cone (Outer) 1 98384
Forward Axle
Planetary Double Reduction
TP/SP461
TP/SP521
TP/SP601
TP/SP651
Note: Pinion Bearing Spacer information is found in Appendix: Gear & Pinion Information
