Spicer Kits & Small Parts Section of J300P - Manual (Page 8)

8 Important: See Safety Information in General Information Section (J300P-GI)
J300P-9A
Center Bearing Detail
• Part is discontinued „ Part is available until supply is exhausted Ž Not sold separately
A = 1.181 Bearing I.D. D = 6.890 Bolt Hole/Stud Size = .787 X .512 (H)
212165-1X 1.440 2.268 ~ 212163X 580931 ~ ~ ~ ~
E = 2.087; 212165-1X will be replaced by 5009385 when supply is exhausted
212166-1X• 1.440 2.268 ~ 212164X 580931 ~ ~ ~ ~
E = 1.693
5009385 1.440 2.268 ~ 5009383 580931 ~ ~ ~ ~
E = 2.087
A = 1.181 Bearing I.D. D = 3.937 Bolt Hole/Stud Size = .750 (H)
212244-1X 2.480 ~ 233031 211983X 580921-1 ~ ~ 232520 ~
Parts not sold separately — Shown for informational purposes only
B C Center Bearing Major Parts Retainers
Center Front Rear
Bearing Centerline Bracket Rubber Bearing & Slinger Slinger
Assy Part To Mounting Bracket Part Cushion Retainer Part Part
Number Surface Width Number Part Nbr. Assy. Number Number Bottom Top
Style 8
Parts not sold separately — Shown for informational purposes only
B C Center Bearing Major Parts Retainers
Center Front Rear
Bearing Centerline Bracket Rubber Bearing & Slinger Slinger
Assy Part To Mounting Bracket Part Cushion Retainer Part Part
Number Surface Width Number Part Nbr. Assy. Number Number Bottom Top
Style 9
