18 Important: See Safety Information in General Information Section (J300P-GI)
J300P-9A
Center Bearing Detail
• Part is discontinued „ Part is available until supply is exhausted Ž Not sold separately
A = 1.968 Bearing I.D. D = 7.620 Bolt Hole/Stud Size = M12 X 1.75TH (nut)
212156-1X 2.780 2.250 212229X 230167-1 550788 230166 230166 ~ ~
212229X consists of 232953 bracket and (2) nuts attached to bracket
Part has been discontinued; offered until supply is exhausted
A = 1.771 Bearing I.D. D = 7.620 Bolt Hole/Stud Size = M12 X 1.75TH (nut)
212145-1X 2.689 2.250 212222X 212133X 580932 ~ ~ ~ ~
232930 Boot Can; Rubber cushion with canister; nuts attached to bracket
A = 1.968 Bearing I.D. D = 7.620 Bolt Hole/Stud Size = M12 X 1.75TH (nut)
212153-1X 2.780 2.250 212229X 212141X 580933 ~ ~ ~ ~
232944 Boot Can; Rubber cushion with canister; nuts attached to bracket;
Part has been discontinued; offered until supply is exhausted
Parts not sold separately — Shown for informational purposes only
B C Center Bearing Major Parts Retainers
Center Front Rear
Bearing Centerline Bracket Rubber Bearing & Slinger Slinger
Assy Part To Mounting Bracket Part Cushion Retainer Part Part
Number Surface Width Number Part Nbr. Assy. Number Number Bottom Top
Style 23
Parts not sold separately — Shown for informational purposes only
B C Center Bearing Major Parts Retainers
Center Front Rear
Bearing Centerline Bracket Rubber Bearing & Slinger Slinger
Assy Part To Mounting Bracket Part Cushion Retainer Part Part
Number Surface Width Number Part Nbr. Assy. Number Number Bottom Top
Style 24
