Spicer Kits & Small Parts Section of J300P - Manual (Page 10)

10 Important: See Safety Information in General Information Section (J300P-GI)
J300P-9A
Center Bearing Detail
• Part is discontinued „ Part is available until supply is exhausted Ž Not sold separately
A = 1.181 Bearing I.D. D = 5.906 Bolt Hole/Stud Size = 1.201 X .551 (H)
5002007 .244 2.244 ~ ~ ~ ~ ~ ~ ~
A = 1.259 Bearing I.D. D = 5.880 Bolt Hole/Stud Size = .500 (H)
211571X 1.690 1.420 211478-1X 580917 231000 231596 ~ ~ ~
A = 1.378 Bearing I.D. D = 6.620 Bolt Hole/Stud Size = .560 (H)
211985X• 2.750 1.226 231247 232615 580923 ~ ~ ~ ~
Has a 1/2" spacer attached to bracket, rubber cushion w/canister
A = 1.574 Bearing I.D. D = 6.620 Bolt Hole/Stud Size = .560 (H)
5003684 2.750 1.226 231247 212027X 580924 ~ ~ ~ ~
Has a 1/2" spacer attached to bracket, rubber cushion w/canister; less boot can
Parts not sold separately — Shown for informational purposes only
B C Center Bearing Major Parts Retainers
Center Front Rear
Bearing Centerline Bracket Rubber Bearing & Slinger Slinger
Assy Part To Mounting Bracket Part Cushion Retainer Part Part
Number Surface Width Number Part Nbr. Assy. Number Number Bottom Top
Style 12
Parts not sold separately — Shown for informational purposes only
B C Center Bearing Major Parts Retainers
Center Front Rear
Bearing Centerline Bracket Rubber Bearing & Slinger Slinger
Assy Part To Mounting Bracket Part Cushion Retainer Part Part
Number Surface Width Number Part Nbr. Assy. Number Number Bottom Top
Style 13
