EN-30
Ranger™ 3000
Series
7. TECHNICAL DATA
The technical data is valid under the following ambient conditions:
Indoor use only
Operating temperature: -10°C to 40°C
Relative humidity: 20% to 85% relative humidity, non-condensing
Altitude: Up to 2000 m
Power: AC power 100-240V 50/60 Hz, internal rechargeable sealed lead acid battery
Current rating: 0.5A
Mains supply voltage fluctuations: up to ± 10% of the nominal voltage
Installation category: II
Pollution degree: 2
7.1 Specifications
TABLE 7-1. SPECIFICATIONS
MODEL R31P1502 R31P3 R31P6 R31P15 R31P30
Capacity x
Readability
(Max x d non-
approved)
1.5 kg x 0.00005 kg
1500 g x 0.05 g
3 lb x 0.0001 lb
48 oz x 0.002 oz
3 kg x 0.0001 kg
3000 g x 0.1 g
6 lb x 0.0002 lb
96 oz x 0.004 oz
6 kg x 0.0002 kg
6000 g x 0.2 g
15 lb x 0.0005 lb
240 oz x 0.01 oz
15 kg x 0.0005 kg
15000 g x 0.5 g
30 lb x 0.001 lb
480 oz x 0.02 oz
30 kg x 0.001 kg
30000 g x 1 g
60 lb x 0.002 lb
960 oz x 0.04 oz
Maximum Displayed
Resolution
1:30000
Capacity x
Readability
(Max x e approved)
1.5 kg x 0.0005 kg
1500 g x 0.5 g
3 lb x 0.001 lb
48 oz x 0.02 oz
3 kg x 0.001 kg
3000 g x 1 g
6 lb x 0.002 lb
96 oz x 0.04 oz
6 kg x 0.002 kg
6000 g x 2 g
15 lb x 0.005 lb
240 oz x 0.1 oz
15 kg x 0.005 kg
15000 g x 5 g
30 lb x 0.01 lb
480 oz x 0.18 oz
30 kg x 0.01 kg
30000 g x 10 g
60 lb x 0.02 lb
960 oz x 0.36 oz
Approved
Resolution
1:3000
Repeatability  0.0001 kg  0.0002 kg  0.0005 kg  0.001 kg  0.002 kg
Linearity  0.0001 kg  0.0002 kg  0.0005 kg  0.001 kg  0.002 kg
Weighing Units
LFT OFF: g, kg, lb, oz, lb:oz
LFT ON: g, kg, lb, oz
EC and OIML Approved models: g, kg
Tare Range To capacity by subtraction
Stabilization Time ≤ 1 second
Weight Display LCD
LCD with white LED backlight
6-digit 7-segment, 28 mm / 1.1 inches digit height
Keyboard 5 mechanical buttons
Application Modes
Weighing, Dynamic Weighing / Display Hold, Counting, Check Weigh, Check Counting, Check Percent,
Percent Weighing, Accumulation
Battery Operating
Time (at 20ºC)
210 hours for LCD version with backlight turned off
Construction ABS plastic housing with 304 stainless steel platform
Approval Class III
Pan Dimensions 225 x 300 mm / 8.9 x 11.8 in
Shipping
Dimensions
397 x 447 x 195 mm / 15.6 x 17.6 x 7.7 in
Net Weight 4.2 kg / 9.3 lb
Gross Weight 5.45 kg / 12 lb
