Ranger™ 3000
Series EN-13
For menu items with numeric settings such as Capacity, the current
setting is displayed with all digits flashing.
Press the No button to begin editing.
The first digit is displayed flashing.
Press the No button to increment the digit or press the Yes button to
accept the digit and move to the next digit.
Repeat this process for all digits.
Press the Yes button when the last digit has been set.
The new setting is displayed with all digits flashing. Press the Yes
button to accept the setting or press the No button to resume editing.
This method also applies to setting Checkweigh under and over
targets.
For End menu items, pressing the Yes button advances to the next
menu, while pressing the No button returns to the top of the current
menu.
4.2 Calibration Menu
Enter this menu to perform calibrations.
Initial Calibration
When the scale is operated for the first time, a span calibration is recommended to ensure
accurate weighing results. Before performing the calibration, be sure to have the appropriate
calibration weights as listed in table 4-1. Ensure that the LFT switch/calibration lock is set to
unlocked position. See figure 5-1.
Or adjust the GEO setting according to your location (see table 4-2).
Procedure:
Press and hold Menu until [mMeNU] (Menu) is displayed. When the button is released, the display
will show [C.A.L]. Press Yes to accept. [SpaN] will then be shown. Press Yes to begin the span
calibration. [ 0 kg ] will be displayed. Press Yes to accept. [--C--] will be displayed while zero
reading is stored. Next, the display shows the calibration weight value. Place the specified
calibration mass on the pan. Press Yes to accept the weight or No to select an alternate weight.
[--C--] will be displayed while the reading is stored. The display will show [done] if the calibration
was successful. The scale returns to the previous application mode and is ready for use.
TABLE 4-1
Required Span Calibration Mass (sold separately)
Max Mass
*
Max Mass
*
1500g 1.5kg / 3lb 15000g 15kg / 30lb
3000g 3kg / 6lb 30000g 30kg / 60lb
6000g 6kg / 15lb
Note:
When active unit is g or kg, the calibrating unit will be in kg.
When active unit is lb, oz or lb:oz, the calibrating unit will be in lb.
For linearity calibration, the calibration Mass is fixed.
Mid-point is always half of full capacity.
