background image

Settings in the menu

Ranger RC

31

4.6 Configuring interfaces (COMMUNICATION)

4.6.1

COM1/COM2 -> MODE – operating mode of the serial interface

4.6.2

COM1/COM2 -> PRINTER – settings for protocol printout
This menu item only appears if the mode "Print" or "A.Print" is selected.

Print

Manual data output to the printer with

PRINT

A.Print

Automatic output of stable results to the printer (e. g. for series weighing operations)

CONtINU

Ongoing output of all weight values via the interface

dIALOG

Bi-directional communication via OHAUS or MT-SICS commands, control of the
scale via PC

CONt.OLd

As per CONtINU, see above, but with 2 fixed blanks in front of the unit (compatible
with Spider 1/2/3)

dIAL.OLd

As per dIALOG, see above, but with 2 fixed blanks in front of the unit (compatible
with Spider 1/2/3)

dt-b

DigiTOL-compatible format.

GROSS

Transfer of the gross weight, identified with "G"

tArE

Transfer of the tare weight

nEt

Transfer of the net weight

dt-G

As per dt-b, see above, gross weight identified with "G"

COnt-Wt

TOLEDO Continuous mode

COnt-Ct

TOLEDO Continuous mode, transfer of the number of pieces

2nd.dISP

For connecting a second display (automatically activates the 5-V voltage supply at
Pin 9)

rEF

Data transfer from the reference scale (automatic switchover)

bULK

Data transfer from the quantity scale (automatic switchover)

AuXILIA

Data transfer from the reference or quantity scale (manual switchover)

tEmPLat

Selecting protocol printout

StdArd

Standard printout

tEmPLt1

Printout in accordance with Template 1

tEmPLt2

Printout in accordance with Template 2

ASCi.FmtT

Selecting formats for the protocol printout

LINE.Fmt

Line format: MULtI (multi-line) or SINGLE (single-line)

LENGtH

Line length: 0 ... 100 characters, appears only with line format MULtI

SEPArAt

Separator: , ; . / \ _ and space; appears only with line format SINGLE

Add LF

Line feed: 0 ... 9
